SKF 7310 BEGAP

B007VGVKHS

SKF 7310 BEGAP Medium Series Angular Contact Bearing, Light Preload, ABEC 1 Precision, 40? Contact Angle, Open, Polyamide/Nylon Cage, Normal Clearance, 50mm Bore, 110mm OD, 27mm Width

SKF 7310 BEGAP Medium Series Angular Contact Bearing, Light Preload, ABEC 1 Precision, 40? Contact Angle, Open, Polyamide/Nylon Cage, Normal Clearance, 50mm Bore, 110mm OD, 27mm Widthzoom

Attributes

Key Value
ABEC Tolerance3
Bore1.969 Inch | 50 Millime.
Bore Dia.50 mm
Bore Diameter50 mm
Bore TypeCylindrical
BrandSKF
Cage MaterialPolymer, PA66
Category - BDIAngular Contact Ball Be.
Closure TypeNone
Contact Angle40 Degree
Contact Angle (Degree)40
Current Stock1
Dynamic Load Capacity (.16,900
Dynamic Load Capacity (.75,000
EAN7316577150639
EnclosureOpen
Extended Lead TimeShips in 5 business days
Flush GroundYes
Harmonized Tariff Code8482.10.50.28
Housing Fillet Radius1 mm
Inch - MetricMetric
Inner Diameter50 mm
Internal ClearanceC0-Medium
International ShippingNo
ItemAngular Contact Ball Be.
Keyword StringAngular Contact
Long Description50MM Bore; 110MM Outsid.
LubricationMT47 Grease
Manufacturer Item Number7310 BEGAP
Manufacturer NameSKF
Max. RPM8,000 RPM
Maximum Capacity / Fill.No
Maximum Temperature100 Degrees C
Minimum Buy QuantityN/A
Mounting ArrangementUniversal
Mpn7310 BEGAP
NounBearing
Number of Bearings1 (Single)
Number of RowsSingle
Number of Rows of BallsSingle Row
O.D. (in)4 1/3
Outer Diameter110 mm
Outside Dia.110 mm
Outside Diameter110 mm, 4.331 Inch | 11.
Overall Width27 mm
Precision ClassABEC 3 | ISO P6
PreloadLight
Preload & Internal Clea.Light Preload
Product Group - BDIB00308
Rolling ElementBall Bearing
Series7300 Series
Shaft Fillet Radius1 mm
SKUZO-G7901625
Snap RingNo
Standard Preload (lbs.)36
Standard Preload (N)160
Static Load Capacity (L.11,500
Static Load Capacity (N)51,000
Static Load Rating51 kN
SubCategoryPower Transmission
Temp. Range (F)-40 Degrees to 212 Deg.
TypeSingle Row Explorer
UNSPSC31171531
UPC Code7316577150639
Weight / Kilogram1.04
Weight / LBS2.288
Width1.063 Inch | 27 Millime.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomBDI Express1421320176.744602761In StockSKF2.288176.74460276 @ 1
thumbzoomMRO Supply313954189.21In StockSKF Bearing189.2 @ 1
factorysupplyoutlet.comWO41RD201.51In Stock25SKF201.5 @ 1
thumbzoomZoroG7901625211.9911Skf2.6211.99 @ 1
us.rs-online.com73220887232.621In StockSKF Bearings232.62 @ 1
thumbzoomsimsupply.comZO-G7901625250.971In StockSkf250.97 @ 1
thumbzoomNational Supply Network45670676265.111In StockSKF265.11 @ 1
thumbzoomsustainablesupply.comC1573087266.181In StockSKF2.6266.18 @ 1
motionindustries.com00060440310.151In StockSKF310.15 @ 1
thumbzoombscsource.com45670676384.691In StockSKF384.69 @ 1
