Cooper Bussmann JCW-1E

Cooper Bussmann JCW-1E Buss High Voltage Fuse, E Rated

mpn JCW-1E
brand name: BUSSMANN
manufacturer name: BUSSMANN

Brand: Cooper Bussmann
PartNumber: JCW-1E
Model: JCW-1E
PackageQuantity: 1
Binding: Misc.
Manufacturer: Cooper Bussmann
Label: Cooper Bussmann

Attributes

Key	Value
AC Voltage Rating	2750/5500V AC
Alarm Contact	No
Amperage Rating	1
Amps	1, 1 A
Application	Utility - Substations, Utility Transmission and Distribution, Primary protection of medium voltage potential transformers, small medium voltage service transformers, and mall medium voltage control.
Applications	Transformer Protection
Approval Agency	-
Body Material	Fiberglass
Body Style	Cylindrical
Brand	Eaton Bussmann series
Breaking Capacity @ Rated Voltage	40kA
Catalog Number	JCW-1E
Category	Circuit Protection
Characteristic	Current Limiting
Class	Class E, E, E-Rated
Connection	Ferrule end x ferrule end
Country of Origin	MX - Mexico, Mexico
Current Rating	1 A
Current Rating (Amps)	1A
DC Voltage Rating	Not Rated
Diameter	1-9/16"
Diameter (in)	1.563 "
ECCN	EAR99
Element	Single
Equivalent Brand and Series	Bussmann JCW
Equivalent Series	JCW
Family Series	Bussmann Fuses, JCW Series
Features	-
Fits Fuse Block Style	Nonrejection
Fuse Amps	1A
Fuse Interrupt Rating	80kA (Asym.) at 4800VAC, 50kA (Sym.) at 4800VAC
Fuse Size	7-5/16" L x 1-9/16" dia
Fuse Speed	Time Delay
Fuse Type	Cartridge
Fuse Voltage Rating	2750/5500VAC
Gross Weight	0.41 lbs
Height	7.46 in.
Interrupt Rating	60 kA @ 5,500 V, 40 kAIC, 50kA (Sym.) at 4800V AC, 80kA (Asym.) at 4800V AC
Interrupt Rating DC	40
Item	Medium Voltage Fuse
Item Number	JCW-1E
Item Type	Fuse
Length	1.63 in., 7-5/16"
Length (Straight Wireway)	7 5/16 in
Made in USA	No
Manufacturer	Eaton Bussmann, Bussmann
Manufacturer Part Number	JCW-1E
Mfr	Eaton - Bussmann Electrical Division
Mounting Type	Holder
Net Weight	1.1 lbs
Operating Temperature	-
Package	Bulk
Package / Case	Cartridge, Non-Standard
Package Type	Cartridge
Part Status	Active
Product Series	JCW
Rated Voltage	2.4 kV, 5.5 kV
Rejection / Nonrejection	Nonrejection
Response Time	-
RoHS	No
Series	JCW
Shape	Rectangular
Size	7.31 In Length
Size / Dimension	1.563" Dia x 7.312" L (39.70mm x 185.72mm)
Speed	Time Delay
Standard	Contact factory
Sub Brand	Bussmann Series
Trip Indicator	No
Type	Current Limiting, Current-Limiting
UNSPSC	39121626
UPC	051712694018
Visual Indication	Nonindicating
Voltage (AC)	2,750 VAC, 5,500 VAC
Voltage Rating	2.4 kV, 5.5 kV
Voltage Rating - AC	5.5 kV
Width	1.63 in.

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Brand	Weight	Preferred Tier
AI Consolidated	JCW-1E-BUSSMANN	253.08	1	In Stock	Bussmann Eaton Cooper Fuses	1.1	253.08 @ 1
Waldom	EATON JCW-1E	289.39	1	In Stock	Eaton		289.39 @ 1
sustainablesupply.com	C1202714	410.11	1	In Stock	Eaton	1.05	410.11 @ 1
Zoro	G2511153	436.99	1	In Stock	Eaton Bussmann	1.05	436.99 @ 1
Digi-Key	5435660	440.77	1	In Stock	Eaton - Bussmann Electrical Division		440.77 @ 1
Galco	JCW-1E-BUSS	552.12	1	In Stock	Bussmann	1.1	552.12 @ 1
kempstoncontrols.co.uk	JCW-1E	628.040088	1	In Stock	Bussmann		628.040088 @ 1
Platt.com	0959354	719.35	1	In Stock	Eaton/Bussmann Series		719.35 @ 1
Newark	02B3968	760.02	1	In Stock	EATON BUSSMANN		760.02 @ 1
crescentelectric.com	1368037	768.02	1	In Stock	Eaton Bussmann series		768.02 @ 1
Raptor Supplies	AE2MEP	1009.8721035	1	In Stock	BUSSMANN		1009.8721035 @ 1
Graybar	88051592	1314.2416	1	In Stock	Bussmann (Eaton)		1314.2416 @ 1
