Schneider LC1K09008B7 Contactor 4P 2NO+2NC 20A 24V AC Coil

Schneider LC1K09008B7 Contactor 4P 2NO+2NC 20A 24V AC Coilzoom

Attributes

Key Value
[Icw] Rated Short-Time .90 A 50 ?C - 1 s power .
[Ith] Conventional Free.20 A 60 ?C power circui.
[Uc] Control Circuit Vo.24 V AC 50/60 Hz
[Ui] Rated Insulation V.power circuit 600 V UL .
[Uimp] Rated Impulse Wi.8 kV
Ambient Air Temperature.-50-80 ?C
Applicationresistive load
Average Impedance3 mOhm - Ith 20 A 50 Hz.
BrandSchneider Electric
California Proposition .Antimony oxide & Antimo.
Catalog NumberLC1K09008B7
China Rohs RegulationPro-active China RoHS d.
Circularity ProfileENVEOLI1503003EN
Coil Power Rating4.5-4.5 VA 20 A Degrees.
Coil Voltage24 V AC 50/60 Hz
ConnectionSCREW CLAMP TERMINALS 1.
Connections - Terminalsscrew clamp terminals 1.
Contact Configuration1 NC, 2 NO + 2 NC
Contact Current Rating9 A
Contact Form2NO ; 2NC
Contact Rating20 A 50 A Degrees C POW.
Contactor Applicationresistive load
Control Circuit TypeAC 50/60 Hz
Control Circuit Voltage.operational 0.8...1.15 .
Control Voltage24 V
Country of OriginFrance
Depth57 mm
Device Applicationcontrol
Device Short NameLC1K
Environmental DisclosureENVPEP1503003EN
Eu Rohs DirectiveCompliant
Flame RetardanceV1 conforming to UL 94 .
Heat Dissipation1.3-1.3 W
Height58 mm
Hold-In Power Consumpti.4.5-4.5 VA 20 ?C)
Inrush Power In Va30-30 VA 20 ?C)
Ip Degree Of ProtectionIP2X VDE 0106
Irms Rated Making Capac.110 A AC power circuit .
Item TypeContactor;LC1K
Made in USANo
ManufacturerSchneider Electric
Maximum Operating Rate3600 cyc/h
Mechanical Durability10 Mcycles
Mechanical Robustnessshocks contactor closed.
Mercury FreeYes
MountingRail Plate
Mounting Supportplate || rail
Mounting TypeDIN Rail Mount
Net Weight0.18 kg
Number of Poles1
Operating Altitude6561.68 ft (2000 m) wit.
Operating Cycles3600 CYC/H,
Operating Temperature-25-50 A Degrees C
Operating Time10...20 ms coil de-ener.
Overvoltage CategoryIII
Pole Contact Composition2 NO + 2 NC
Poles Description4P
Power Rating8 kW
Product CertificationsCB Scheme || CCC || UL .
Product Or Component Ty.contactor
Protective TreatmentTC IEC 60068 || TC DIN .
RangeTeSys
Rated Breaking Capacity110 A 220...230 V IEC 6.
Reach Free Of SvhcYes
Reach RegulationFree of Substances of V.
Rohs Exemption Informat.Yes
Safety Reliability LevelB10d = 1369863 cycles c.
SeriesTeSys Micra Series
Size45 MM,57 MM,58 MM
Special Features20 A AT
StandardBS 5424-IEC 60947-NF C .
StandardsBS 5424 ; IEC 60947 ; N.
Sub BrandTESYS K
Sustainable Offer StatusGreen Premium product
Terminal TypeScrew Clamp
Tightening Torque0.8-1.3 N.m screw clamp.
Toxic Heavy Metal FreeYes
UPC785901141235
UPC Code785901141235
Utilisation CategoryAC-1
Warranty18 months
Warranty DescriptionContractual Warranty:18.
WeeeThe product must be dis.
Width45 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
RS Delivers609-015044.772135Schneider Electric44.772 @ 1
thumbzoommayerelectric.comSQDLC1K09008B788.771In StockSCHNEIDER ELECTRIC0.39688.77 @ 1
thumbzoomcrescentelectric.com14029797.281In StockSchneider Electric97.28 @ 1
us.rs-online.com70379411105.0911Schneider Electric105.09 @ 1
Newark79C9825114.011In StockSCHNEIDER ELECTRIC114.01 @ 1
