MEAN WELL RSD-300F-24

mpnRSD-300F-24
brandname: Mean Well
manufacturername: Mean Well

Mean Well Dc-Dc Converter, 24V, 12.5A - RSD-300F-24

Mean Well Dc-Dc Converter, 24V, 12.5A - RSD-300F-24

zoom

Brand: MEAN WELL
PartNumber: RSD-300F-24
Manufacturer: Mean Well
Label: Mean Well

Attributes

Key	Value
Applications	ITE (Commercial), Railw.
Approval Agency	CE
ASIN	B071RXJQH5
Current - Output (Max)	12.5A
DC Current (Typ.)	3.25A / 72V
Dimension	216 x 97 x 40mm (LxWxH)
Dimensions	216 x 97 x 40mm (L x W .
Efficiency	91%
Efficiency (Typ.)	89%
EMC Emission	Compliance to EN55022 (.
EMC Immunity	Compliance to EN61000-4.
Hold up Time	F-Type complies with S2.
Industry Aliases	new
Inrush Current (Typ.)	45A / 72VDC
Is Discontinued By Manu.	No
Isolation Resistance	I/P - O/P, I/P-FG, O/P-.
Item model number	RSD-300F-24
Line Regulation	?0.5%
Load Regulation	?1.0%
Mfr	MEAN WELL USA Inc.
Mounting Type	Chassis Mount
MTBF	130.7Khrs min. MIL-HDBK.
Number of Outputs	1
Operating Temperature	-40?C ~ 70?C (With Dera.
Output Voltage	24V
Over Temperature	F - type : 110?C ?5?C (.
Over Voltage	5.75 ~ 7V
Overload	105 ~ 135%
Packing	1.19Kg; 12pcs / 15.3Kg .
Part Status	Active
Power (Watts)	300W
Railway Standard	Meet EN50155 / IEC60571.
Safety Standards	Meet IEC60950-1 (LVD)
Setup, Rise Time	800ms, 50ms at full load
Size / Dimension	8.50" L x 3.80" W x 1.5.
Storage Temp., Humidity	-40 ~ +85?C, 5 ~ 95% RH
Temp. Coefficient	?0.03%/?C (0 ~ 50?C)
Type	Enclosed
Vibration	10 ~ 500Hz, 5G 10min. /.
Voltage - Input (Max)	93.6V
Voltage - Input (Min)	50.4V
Voltage - Isolation	4000 V
Voltage - Output 1	24V
Voltage - Output 2	-
Voltage - Output 3	-
Voltage - Output 4	-
Voltage Range 1 sec.	43.2 ~ 100.8 VDC
Voltage Range Continuous	50.4 ~ 93.6 VDC
Voltage Tolerance	?2.0%
Wattage	300
Withstand Voltage	I/P - O/P : 4KVAC I/P-F.
Working Humidity	5 ~ 95% RH non-condensi.
Working Temp.	-40 ~ +55?C (no deratin.

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	peaktopeakpower.com	RSD-300F-24	103.0	1	In Stock		Mean Well		103.0 @ 1
	Onlinecomponents.com	RSD-300F-24	107.3	1	In Stock		Mean Well		107.3 @ 1
	Digi-Key	RSD-300F-24-ND	118.65083	12	In Stock		MEAN WELL USA Inc.		118.65083 @ 12
	Newark	44AC7370	148.28	1	In Stock		MEAN WELL		148.28 @ 1
	electricautomationnetwork.com	RSD-300F-24	165.36	1	In Stock		MEANWELL		165.36 @ 1
	AmazonSC	B071RXJQH5	169.42	1	In Stock		MEAN WELL		169.42 @ 1
