NTN SUCFL210-31

B007ICK0TY

NTN 1-15/16"-SS 2B.FLG-SS FG3BRG (SUCFL210-31)

NTN 1-15/16"-SS 2B.FLG-SS FG3BRG (SUCFL210-31)zoom

Attributes

Key Value
Back Side to Center Wid.0.866 in
Bearing Housing Materia.Stainless Steel
Bearing Insert Material440C Stainless Steel
Bearing Insert TypeBall
Bearing TypeBall Bearing
Bolt Hole Center-to-Cen.157 mm
Bolt SizeM16
Bore Dia.1 15/16 in
Bore Diameter1 15/16 in
Dimension A197 mm
Dimension E157 mm
Dimension G16 mm
Dimension L40 mm
Dimension N19 mm
Dimension S19 mm
FinishChrome
Max Rotational Speed2900 RPM
Mount Hole Center-to-Ce.6 3/16 in
Mount Hole Center-to-Ce.6 3/16 in
Mount Hole Size0.748 in
Mounting Bolt Size5/8 in
Operating temperature r.-4 to 250 F
Overall Height54.6 mm
Overall Length190 mm
Overall Width115 mm
Seal materialSilicone
Seal typeContact
SeriesCorrosion Resistant wit.
Shaft Locking TypeSet Screws

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG2318906458.911In Stock13Ntn4.69458.91 @ 1
thumbzoomMRO Supply827951508.531In StockNTN Bearing508.53 @ 1
thumbzoomRaptor SuppliesAE6KXZ967.72566151In StockNTN967.7256615 @ 1
