Dwyer BT20S54571

B00F34SNA2

Dwyer Sanitary Bimetal Thermometer, BT20S54571, 50-550?F, 5" Dial, 2" Clamp, 4.5" Stem

Dwyer Sanitary Bimetal Thermometer, BT20S54571, 50-550?F, 5" Dial, 2" Clamp, 4.5" Stemzoom

Attributes

Key Value
3-A CertifiedNo
Accuracy+/-1%
AdjustmentsExternal
Calibration TypeCoC
CaseHermetically Sealed
Case FeaturesHermetically Sealed
Case MaterialStainless Steel
Connection LocationBack
Connection Size2 in Sanitary
Construction316 Stainless Steel Hou.
Country of Origin (subj.United States
Dial Diameter5 in
Dial Size5 in
Flange Material316/316L Stainless Steel
Housing Material316 Stainless Steel
Includes NIST-Traceable.No
ItemSanitary Dial Thermomet.
Lens MaterialGlass
Manufacturer Warranty L.1 yr
Manufacturers Warranty .1 yr
Maximum Temperature ?F550 Degrees F
Maximum Temperature F550 Degrees F
Minimum Temperature ?F50 Degrees F
Minimum Temperature F50 Degrees F
NSF RatedNo
Process Connection2 in Triclamp
ScaleFahrenheit
Scale TypeDial
Sensing ElementBimetal
Stem Dia.1/4 in
Stem Length4.5 in
Stem Material316 Stainless Steel
Temp. Range (F)50 Degrees to 550 Degr.
Temperature Graduations2 Degrees F
Temperature Range50 Degrees to 550 Degr.
Window MaterialGlass
