Rexnord MF5307S

mpnMF5307S
brandname: REXNORD
manufacturername: REXNORD

Rexnord MF5307S Double Set Collar Flange Block, 4-Bolt Piloted Flange, Double Setscrew Locking Collar, Non-Expansion, Heavy Contact Seals, Cast Iron, 3-7/16" Shaft-Size, 6-23/32" Bolt Spacing, 9-1/2" Bolt Circle

Rexnord MF5307S Double Set Collar Flange Block, 4-Bolt Piloted Flange, Double Setscrew Locking Collar, Non-Expansion, Heavy Contact Seals, Cast Iron, 3-7/16" Shaft-Size, 6-23/32" Bolt Spacing, 9-1/2" Bolt Circle

zoom

Brand: Rexnord
PartNumber: MF5307S
PackageQuantity: 1
Binding: Misc.
Manufacturer: Rexnord
Label: Rexnord

Attributes

Key	Value
bearing type:	Spherical Roller
Bolt Spacing	6.719 Inch \| 170.663 Mi.
Bore	3.438 Inch \| 87.325 Mil.
bore type:	Round
Brand	REXNORD
Cartridge Pilot Depth	0.188 Inch \| 4.775 Mill.
Cartridge Pilot Diameter	7.375 Inch \| 187.32 Mil.
Category	Flange Block Bearings
EAN	698210702540
Expansion / Non-expansi.	Non-expansion
expansion type:	Non-Expansion Bearing (.
finish/coating:	Powder Coated
flange mounting type:	Four-Bolt Square
Global Part Number GPN	555202
Harmonized Tariff Code	8483.20.40.80
Housing Configuration	1 Piece Solid
Housing Material	Cast Iron
housing material:	Cast Iron
Housing Style	4 Bolt Square Flange Bl.
Inch - Metric	Inch
Insert Part Number	5307U
Length Thru Bore	5.313 Inch \| 134.95 Mil.
locking device:	Double Concentric Collar
lubrication type:	Lubrication Fitting
Manufacturer Name	REXNORD
maximum rpm:	1400 RPM
Mounting Bolts	3/4 Inch
Mounting Method	Concentric Collar
Nominal Bolt Circle Dia.	9.5 Inch \| 241 Millimet.
Number of Mounting Holes	4
Other Features	Double Row \| Double Col.
overall depth:	5-5/16 in
Pilot Configuration	With Pilot
price	$ 1,852.29 / each
radial dynamic load cap.	82000 lb
radial static load capa.	91900 lb
Relubricatable	Yes
seal type:	Contact/Lip
Seals	Heavy Contact
series:	5000
standards met:	ANSI/ABMA STD 9-1990
title	MF5307S
UNSPSC	31171501
Weight / LBS	38

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Lily Bearing	MF5307S	1574.45	1	In Stock		REXNORD	38.0	1574.45 @ 1
	Radwell	MF5307S	2700.0	1	In Stock		REXNORD		2700.0 @ 1
	motionindustries.com	00573885	2788.17	1	In Stock		Rexnord		2788.17 @ 1
