- mpnFAZ-D1/2-NA
- brandname: Eaton / Cutler Hammer
- manufacturername: Eaton / Cutler Hammer
Eaton FAZ-D1/2-NA IEC Mini Circuit Breaker,1A,2P,277/480V
- Brand: Eaton
- PartNumber: FAZ-D1/2-NA
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: Eaton
- Label: Eaton
Attributes
| Key | Value |
|---|
| AC Voltage Rating | 277/480V AC |
| Actuator Type | Toggle |
| Amperage | 1 |
| Amperage Rating | 1 |
| Amps | 1, 1 A |
| Application | Motor Control Circuits,. |
| Approval | UL, CSA, IEC, CE, VDE |
| Approvals | CSA Std. C22.2 No. 235 . |
| Brand | Eaton |
| Catalog Number | FAZ-D1/2-NA |
| Characteristic | D Curve |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mountin. | DIN Rail |
| Connection | Screw Terminal |
| Connection Type | Feed-Thru |
| Country of Origin | Spain |
| Current Rating | 1 A |
| Curve Type | D |
| DC Voltage Rating | 48/96V DC |
| Depth | 1.5 in |
| Family / Style | FAZ-NA |
| Frame | 45 |
| Frame Size | 40A/FAZ |
| Frame Type | FAZ |
| Frequency Rating | 50-60 Hz |
| Functions | LI - Long Time and Inst. |
| Height | 4.13 Inch |
| Interrupt Rating | 14 kAIC|10 kAIC |
| Interrupt Rating AC | 10 kA |
| Interrupting Rating | 14kAIC, 10kAIC |
| Item | IEC Miniature Circuit B. |
| Item Type | Branch protector |
| Length | 3.0 in, 1.4 in |
| Length (Straight Wirewa. | 3.0 in |
| Made in USA | No |
| Manufacturer | Eaton Cutler Hammer, Ea. |
| Max Wire Size | 6 AWG |
| Max. AIR Rating | 10kA at 277/480V AC |
| Max. Operating Temp. | 140 Degrees F |
| Max. Wire Size | 6 AWG |
| Min Wire Size | 18 AWG |
| Min. Wire Size | 18 AWG |
| Mounting | DIN Rail |
| Mounting Type | DIN Rail Mount, DIN Rail |
| Mpn | FAZ-D1/2-NA |
| Number of Poles | 2 |
| Part Number | FAZ-D1/2-NA |
| Phase | 1 |
| Poles | 2 |
| Protection | Thermal Magnetic |
| Series | FAZ, FAZ-NA, FAZ-NA Ser. |
| Standard | CSA Std. C22.2 No. 235,. |
| Standards | CSA Certified, IEC 6094. |
| Temperature Rating | -4 to 140?F |
| Terminal Connection | Screw Clamp, Line and l. |
| Terminals | Standard terminals |
| Termination | Screw |
| Trip Range | 10 - 20 x In |
| Trip Type | Thermal Magnetic, 10-20. |
| Type | Trip Curve D, Thermal/M. |
| Upc | 4015081020546 |
| UPC Code | 4015081020546 |
| Voltage | 277/480VAC, 48/96VDC |
| Voltage Rating | 277/480V, 277 ; 480 V |
| Volts AC | 277, 480Y |
| Volts DC | 48 |
| Width | 0 in, 1.39 in |
| Wire Gauge | 18 to 6 AWG, 18 to 10 A. |
| Wire Size | (1) 18-6 AWG, (2) 18-10. |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | motorsandcontrol.com | FAZ-D1/2-NA | 83.4 | 1 | 8 | | Eaton Cutler Hammer | | 83.4 @ 1 |
 | Walker Industrial | FAZ-D1-2-NA | 92.0 | 1 | In Stock | | Eaton Cutler-Hammer | | 92.0 @ 1 |
 | Carlton Bates Company | 01508102054 | 95.6 | 1 | In Stock | | EATON | | 95.6 @ 1 |
 | Platt.com | 0058478 | 101.21 | 1 | 9 | | Eaton | | 101.21 @ 1 |
| us.rs-online.com | 70276032 | 140.04 | 1 | 9 | | Eaton - Cutler Hammer | | 140.04 @ 1 |
 | superbreakers.com | FAZ-D1/2-NA | 142.82 | 1 | 2 | | Eaton | | 142.82 @ 1 |
 | cappusa.com | 4874817 | 145.66 | 1 | In Stock | | Eaton | | 145.66 @ 1 |
 | Raptor Supplies | AF6MFV | 149.9371965 | 1 | In Stock | | EATON | | 149.9371965 @ 1 |
 | Newark | 58M6272 | 153.02 | 1 | In Stock | | EATON CUTLER HAMMER | | 153.02 @ 1 |
 | Zoro | G7487277 | 196.99 | 1 | In Stock | | Eaton | 0.57 | 196.99 @ 1 |
 | crescentelectric.com | 16823 | 314.14 | 1 | In Stock | | Eaton | | 314.14 @ 1 |
| Airline Hydraulics | EATON FAZ-D1/2-NA | 474.25 | 1 | 217 | | Eaton | | 474.25 @ 1 |
