Schneider Electric HJL36125SA

B00CONRH7A

SCHNEIDER ELECTRIC 600-Volt 125-Amp HJL36125SA Molded Case Circuit Breaker 600V 125A

SCHNEIDER ELECTRIC 600-Volt 125-Amp HJL36125SA Molded Case Circuit Breaker 600V 125Azoom

Attributes

Key Value
[Ics] Rated Service Bre.65 kA 220/240 V AC 50/6.
[Ue] Rated Operational .690 V AC 50/60 Hz IEC 6.
[Ui] Rated Insulation V.750 V IEC 60947-2
[Uimp] Rated Impulse Wi.8 kV IEC 60947-2
AC Voltage Rating600VAC
Accessory / Separate Pa.shunt trip 110...130 V .
Actuator TypeToggle
Ambient Air Temperature.-2-70 ?C
Ambient Air Temperature.-50-85 ?C
Amperage Rating125 A, 125
Amps125
Applicationdistribution
Awg GaugeAWG 14...AWG 3/0 alumin.
BrandSquare D by Schneider E.
Breaking Capacity100 kA 240 V AC 50/60 H.
Breaking Capacity CodeJ
California Proposition .DINP, which is known to.
Catalog NumberHJL36125SA
China Rohs RegulationProduct out of China Ro.
Circularity ProfileENVEOLI1311006EN
ColorBlack
Communication InterfaceModbus || Ethernet
ConditionNew
ConnectionLugs line;lugs load; AW.
Connection typeLine/Load Lug
Continuous Current Rati.80 %
Control TypeToggle
Country of OriginUnited States
Country of Origin (subj.United States
Current Rating125 A
Depth86 mm
Device Applicationdistribution
Dimensions4.36 in L x 4.12 in W x.
DisplayHJL36125SA Circuit brea.
Electrical Connectionlugs line || lugs load
Environmental DisclosureENVPEP1311006EN
Estimated Lead Time (in.5
Eu Rohs DirectiveCompliant
FrameJ
Frequency Rating50/60, 50/60 Hz
GTIN785901669173
Height163 mm, 6.42
Interrupt Rating20/25/65/100, 20/25/65/.
Ip Degree Of Protectionfront cover IP40 IEC 60.
ItemMolded Case Circuit Bre.
Item Typecircuit breaker
Length3.39
Length UOMInch
Line Rated Current125-125 A
Local Signallingswitched off (OFF) 1 tr.
Made in USAYes
Magnetic Hold Current900 A
Magnetic Tripping Curre.1700-1700 A
ManufacturerSquare D, Schneider Ele.
Mercury FreeYes
Mounting Modeunit mount lug)
Mounting Supportlug
Mounting typeSurface/Unit
Net Weight2.2 kg
Network Frequency50/60 Hz
Number of Poles3
Number Of Slots2 auxiliary switch OF p.
Operating Temperature40 A Degrees C
OverloadThermal Magnetic
Phase3
Poles Description3P
Pollution Degree3 IEC 60947-1
Product CertificationsUL || CSA || NOM
Product NamePowerPact H
Product Or Component Ty.circuit breaker
Protected Poles Descrip.3t
Pvc FreeYes
Quality LabelsCE
Quantity Per Set1
RangePowerPact
Reach RegulationReference contains Subs.
Rohs Exemption Informat.Yes
Special FeaturesShunt trip 110...130 V .
StandardCCC-CE-UL LISTED-IEC-CSA
StandardsUL || CSA || NEMA || NO.
Suitability For Isolati.yes IEC 60947-2
Sustainable Offer StatusGreen Premium product
Temperature Rating (Deg.40, 40 deg C
Terminal IdentifierAL150HD
Tightening Torque5-5 N.m 2.5-6 mm? (AWG .
Trip Range125 A,1700 A,900 A, 900.
Trip Typethermal-magnetic, Shunt.
Trip Unit Technologythermal-magnetic
TypeType HJL
UPC785901669173
Utilisation Categorycategory A
Voltage Rating250 V DC-600 V AC, 600 .
Warranty18 months
Warranty DescriptionContractual Warranty:18.
Weight2.000000
Width104 mm, 4.09
Wire Size14 to 3/0 AWG Al/Cu
Wire Stripping Length16 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomcappusa.com48114074079.391In StockSquare D4079.39 @ 1
thumbzoomZoroG08551584138.01In Stock60Square D5.04138.0 @ 1
thumbzoomblackhawksupply.comHJL36125SA4356.791In StockSquare D4356.79 @ 1
thumbzoomindustrialrefrigerationparts.comHJL36125SA4461.351In StockSquare D2.04461.35 @ 1
thumbzoomstandardelectricsupply.com22783834832.221In StockSquare D (Schneider Electric)4832.22 @ 1
Newark11R13605106.931In StockSQUARE D BY SCHNEIDER ELECTRIC5106.93 @ 1
thumbzoomgordonelectricsupply.comHJL36125SA5170.01In Stock10SQUARE D5170.0 @ 1
thumbzoomRadwellHJL36125SA5400.01In StockSCHNEIDER ELECTRIC SQUARE D5400.0 @ 1
thumbzoommayerelectric.comSQDHJL36125SA5638.831In StockSQUARE D4.845638.83 @ 1
us.rs-online.com714115916038.071In StockSquare D6038.07 @ 1
thumbzoomcrescentelectric.com1933836324.531In StockSquare D by Schneider Electric6324.53 @ 1
thumbzoomsustainablesupply.comC30466146466.251In StockSquare D5.06466.25 @ 1
