Hayward WCV1800ES

mpnWCV1800ES
brandname: HAYWARD
manufacturername: HAYWARD

Hayward WCV1800ES Series WCV Full Pattern Wafer Check Valve with Spring, PVC with EPDM/SS Seals, 8" Size

Hayward WCV1800ES Series WCV Full Pattern Wafer Check Valve with Spring, PVC with EPDM/SS Seals, 8" Size

zoom

Brand: Hayward
PartNumber: WCV1800ES
Model: WCV1800ES
Color: B01M04LS2H
Size: 8 Inch
PackageQuantity: 1
Binding: Misc.
Manufacturer: Hayward Industries
Label: Hayward Industries

Attributes

Key	Value
Application - Valves	Process Piping
Body Material	PVC
Body Material - Valves	PVC
Connection Type	Flanged
Connection Type - Check.	Flange x Flange
Country of Origin (subj.	United States
Cracking Pressure	1 psi
Cracking Pressure - Che.	1.0 psi
Description:	8" PVC Wafer Full Patte.
Domestic/Import	Domestic
Flow	1225 gpm
Flow - Valves	1,225 gpm
Flow Design	Single
Full Flow - Valves	Yes
Inlet to Outlet Length	4.93 in
Item	Wafer Check Valve
Item - Check Valves	Check Valve
Length	4 15/16 in
Length (Straight Wirewa.	4 15/16 in
Manufacturer	HAYWARD INDUSTRIAL PROD.
Material of Construction	PVC
Max. Pressure	150 psi @ 70 Degrees F
Max. Steam Pressure - V.	Not Rated
Max. Temp.	140 Degrees F
Max. Temp. - Valves	140 Degrees F
Max. Water Pressure	150 psi @ 70 Degrees F
Max. Water Pressure - V.	150 psi @ 70 Degrees F
Mechanism and Body Desi.	Inline Wafer
MFG Part #:	WCV1800ES
Min. Temp. - Valves	40 Degrees F
Mounting Orientation	Horizontal, Vertical
Mounting Orientation - .	Horizontal, Vertical
Mounting Position	Vertical or Horizontal
Nominal Size	8 in
Overall Height	13 3/8 in
Pipe or Tube Size	8 in
Pipe or Tube Size - Che.	8 in
Pipe Size	8"
Port Type	Full
Pressure Rating	150 psi
Seal Material	EPDM
Seal Material - Check V.	EPDM
Seat Material	EPDM
Seat Material - Check V.	EPDM
Series	WCV
Size	8"
Softgoods Material	EPDM
Spring Material	Stainless Steel
Spring Material - Check.	Stainless Steel
Sub-Category	PVC
Supplier:	HAYWARD INDUSTRIAL PROD.
Temperature Rating	70 deg F
Type	Wafer
UPC:	610377188609
Width	10 7/8 in
