24LC02B-I/SN

mpn24LC02B-I/SN
brandname: Microchip Technology Inc.
manufacturername: Microchip Technology Inc.

EEPROM 256x8 - 1.8V (1 piece)

EEPROM 256x8 - 1.8V (1 piece)

zoom

PartNumber: 24LC02B-I/SN
PackageQuantity: 1
Binding: Electronics
Manufacturer: Microchip Technology
Label: Microchip Technology

Attributes

Key	Value
Access Time	900 ns, 100 ns
Alternate Part No.	579-24LC02B-I/SNG
Brand	Microchip Technology
Current, Input, Leakage	1 uA
Current, Output, Leakage	?1 ?A
Data Retention	200 yr, 200 Years
Density	2 kbit
Dimensions	4.90 x 3.90 x 1.50 mm
ESD Voltage	?4 kV
Fall Time	300 ns
Height	0.059" (1.5mm)
Input Capacitance	10 pF
Interface	2-Wire
Interface Type	I2C
Length	0.192 in
Manufacturer	Microchip
Manufacturer Part No.	24LC02B-I/SNG
Maximum Clock Frequency	0.4 MHz
Maximum Operating Curre.	3 mA, 1 mA
Maximum Operating Tempe.	+ 85 C, +85 ?C
Memory Capacity	2 KB
Memory Size	2 kbit
Memory Type	Serial EEPROM
Minimum Operating Tempe.	-40 ?C, - 40 C
Mounting Style	SMD/SMT
Mounting Type	Surface Mount
Number of Bits per Word	8 bit
Number of Pins	8
Operating Current	0.1 mA, 0.05 mA, 0.05 ;.
Operating Supply Voltage	2.5 V to 5.5 V
Operating Temperature	-40 to +85 ?C
Operating Voltage Range	2.5 to 5.5 V
Organisation	256 x 8
Organization	256 x 8
Output Capacitance	10 pF
Package Type	SOIC
Package/Case	SOIC-8
Packaging	Tube
Product Category	EEPROM
Product Header	2K I
Programmable Voltage	2.5 V
Rise Time	300
Series	24LC02B Series
Supply Voltage	2.5-5.5 V
Supply Voltage - Max	5.5 V
Supply Voltage - Min	2.5 V
Temperature Operating R.	-40 to +85 ?C
Voltage, Input, High Le.	1.75 V
Voltage, Input, Low Lev.	0.75 V
Voltage, Output, Low Le.	0.4 V
Width	0 in

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	RS Delivers	178-4064	0.078	1	100		Microchip		0.078 @ 100
	Win Source	24LC02B-I/SN	0.12	200	393		Microchip Technology		0.12 @ 200
	Freelance Electronics	24LC02B-I/SN	0.15167	1	100		MICROCHIP TECH		0.15167 @ 100
	Onlinecomponents.com	24LC02B-I/SNG	0.231	1	100		Microchip Tech.		0.214 @ 101
	Newark	30H1482	0.272	1200	100		MICROCHIP		0.272 @ 1200
	TME	24LC02B-I/SNG	0.298	3	100		MICROCHIP TECHNOLOGY		0.298 @ 100
	swatee.com	24LC02B-I/SNG	0.52	1	721		Microchip		0.52 @ 100
	us.rs-online.com	70045229	0.52	3750	100		Microchip Technology Inc.		0.52 @ 3750
	Component Electronics	24LC02B-I/SN-MICROCH	0.58	1	100		Microchip Technology		0.58 @ 100
