- mpn3 758 N IRON BODY
- brandname: Mueller Steam Specialty
- manufacturername: Mueller Steam Specialty
Y Strainer, 304 SS, 3", Flanged, NonAsbestos
- Brand: Mueller Steam Specialty
- PartNumber: 3 758 N Iron Body
- PackageQuantity: 1
- Manufacturer: MUELLER STEAM SPECIALTY
- Label: MUELLER STEAM SPECIALTY
Attributes
| Key | Value |
|---|
| Blow Off Port | 1 in |
| Blow-off Port | 1" |
| Brand | Mueller Steam Specialty |
| Class | 125 |
| Connection Type | Flanged |
| Current Stock | 11 |
| Cv Flow Factor | 140 gpm |
| For Use With | Steam, Water |
| Height | 8 3/8 in |
| Housing Material | Cast iron |
| Includes Screen | Yes |
| International Shipping | No |
| Item | Y Strainer |
| Length | 10 1/8 in, 10-1/8" |
| Length (Straight Wirewa. | 10 1/8 in |
| Max. Fluid Temp. | 150 Degrees F |
| Max. Pressure | 200 psi @ 150 Degrees F. |
| Maximum Pressure | 125 psi @ 450 Degrees F. |
| Maximum Pressure at 100. | 200 psi |
| Maximum Temperature | 150 Degrees F, 150 Deg. |
| Mesh | 0.062" |
| Mpn | 3 758 N Iron Body |
| Perforated Screen Size | 0.062 in |
| Pipe Size | 3", 3 in |
| Port 1 Connection Size | 3 in |
| Port 1 Connection Type | Flanged |
| Port 2 Connection Size | 3 in |
| Port 2 Connection Type | Flanged |
| Port 3 Connection Size | 1 in |
| Port 3 Connection Type | NPT |
| Screen Area | 0.06 sq. in., 0.06 sq in |
| Screen Material | 304 Stainless Steel |
| Seal Material | Non-Asbestos |
| Series | 758 |
| SKU | ZO-G1447031 |
| Standards | ASSE, CSA, FM, NSF, UL,. |
| Strainer Connection Type | Flanged Connection |
| Strainer Type | Perforated |
| SubCategory | Plumbing |
| UPC | 098268353860 |
