WAGO 2626-3106/020-000

B078117MKZ

WAGO 2626-3106/020-000 2626 Series 6-Pole 11.5 mm Pin Spacing Push-in Cage Clamp PCB Terminal Block - 2 item(s)

WAGO 2626-3106/020-000 2626 Series 6-Pole 11.5 mm Pin Spacing Push-in Cage Clamp PCB Terminal Block - 2 item(s)zoom

Attributes

Key Value
ActuatorOperating tool
ApprovalsCSA, cURus
BrandWAGO
Catalog Number2626-3106/020-000
Colorgray
CompositionPolyamide
Conductor Range8-24 AWG Conductor Range
ConnectionPush-in CAGE CLAMP
Connection ActuationTool
Connection TypeSpring Clamp
Country of OriginGermany
Current Rating48 A
Depth18.5 mm / 0.728 inches
Depth UOMInch
Family SeriesWago Terminal Blocks, 2.
Gross Weight0 lbs
GTIN4055143587341
Height28.2 mm / 1.11 inches
Height UOMInch
IEC Current48 A
IEC Max Wire Size (mm2)10 mm2
IEC Voltage1,000 VAC
IEC Wire Range (mm2)0.2-10 mm2
Item Number2626-3106/020-000
Item TypePCB terminal block
Made in USANo
ManufacturerWAGO
Manufacturer Part Number60331814
MaterialPolyamide (PA66)
MountingFeed-through
Mounting TypePCB Mount
Net Weight0.0506 lbs
Number of Levels1
Number of Poles6
PCB ContactTHT
Pin Length4 mm
Pin Spacing7.5 mm
PluggableNo
Product Series2626
RoHSYes
RoHS IndicatorYes
Temperature Range-76-221 ?F
UL Current38 A
UL Max Wire Size8 AWG
UL Voltage600 VAC
UL Wire Range (AWG)24-8 AWG
Voltage Rating1000
Weight22.914
Weight UOMGrams
Width1.843
Width UOMInch
Wire Entry PositionTop

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Platt.com12020137.6912Wago7.69 @ 2
thumbzoomGalco2626-3106/020-000-WAGO8.48502Wago0.05068.48 @ 50
thumbzoomcrescentelectric.com10767748.7612WAGO8.76 @ 2
thumbzoomNewark44AC111212.14150WAGO12.14 @ 2
thumbzoomAmazonSCB078117MKZ19.1312WAGO19.13 @ 2
