MOLEX 43045-2200 Header (10 pieces)
- Brand: Molex
- PartNumber: 43045-2200
- Model: 43045-2200
- PackageQuantity: 10
Attributes
| Key | Value |
|---|
| Agency Approvals | CSA ; UL ; TUV |
| Alternate Mfr Part Numb. | 430452200 |
| Alternate Part No. | 538-43045-2200 |
| Angle | Right Angle |
| Application | Wire-to-Board |
| Brand | Molex |
| Category | Connectors, Interconnec. |
| Color | Black |
| Connector Type | Male Pin |
| Contact Finish - Mating | 100.0?in (2.54?m) |
| Contact Finish - Post | Brass |
| Contact Finish Thicknes. | Tin |
| Contact Finish Thicknes. | General Purpose, Medica. |
| Contact Gender | Pin (Male) |
| Contact Length - Mating | 0.125" (3.18mm) |
| Contact Length - Post | - |
| Contact Material | Liquid Crystal Polymer . |
| Contact Plating | Tin |
| Contact Shape | Tin |
| Contact Type | 0.118" (3.00mm) |
| Current Rating | 8.5 A, 5 A |
| Current Rating (Amps) | 600V |
| Family Name | Micro-Fit 3.0 |
| Fastening Type | - |
| Features | - |
| For Use With | PCB Right-Angle Header |
| Gender | Male |
| Housing Material | Polyester, Thermoplastic |
| Ingress Protection | UL94 V-0 |
| Insulation Color | 8A |
| Insulation Height | Square |
| Insulation Material | Board Lock |
| Manufacturer | Molex |
| Manufacturer Part No. | 43045-2200 |
| Mated Stacking Heights | - |
| Material Flammability R. | Black |
| Mfr | Molex |
| Mounting Angle | Right |
| Mounting Style | Board Lock |
| Mounting Type | Solder |
| Number of Circuits | 22 |
| Number of Contacts | 22 |
| Number of Positions | 2, 22, 22 Position |
| Number of Positions Loa. | Board to Cable/Wire |
| Number of Rows | 2, 0.118" (3.00mm), 2 R. |
| Operating Temperature | -40 to +105 ?C, - |
| Orientation | Right Angle |
| Overall Contact Length | 0.290" (7.37mm) |
| Overall Length | 0.551 " |
| Package | Active |
| Packaging | Tray |
| Part # Aliases | 0430452200 |
| Part Status | Header |
| Pin Spacing | 0.118 " |
| Pitch | 3.00 mm (0.118"), 3 mm |
| Pitch - Mating | 22 |
| Plating Material | Tin |
| Primary Type | Soft Shell |
| Product | Headers |
| Product Category | Headers & Wire Housings |
| Product Header | Micro-Fit 3.0? Wire-to-. |
| Product Type | Header Assemblies |
| Row Spacing | 3 mm |
| Row Spacing - Mating | All |
| Series | 43045, Tray, 43045 Seri. |
| Shrouding | Through Hole, Right Ang. |
| Special Features | Low-Halogen |
| Standards | UL Listed, CSA Certifie. |
| Style | Shrouded - 4 Wall |
| Temperature Range | -40 to 105 C |
| Termination | Through Hole, Locking R. |
| Termination Style | Through Hole |
| Tradename | Micro-Fit 3.0 |
| Type | Right Angle Header, Pin. |
| Voltage Rating | -, 600 V |
