- mpn15Q05LR56
- brandname: Dodge
- manufacturername: Dodge
Dodge - 15Q05LR56 TIGEAR-2 Reducer
- Brand: Dodge
- PartNumber: 15Q05LR56
- PackageQuantity: 1
- Manufacturer: Dodge
- Label: Dodge
Attributes
| Key | Value |
|---|
| Base to output center h. | 1.8700 in, 47.498 mm |
| Case size | 15 |
| Center distance (in) | 1.5 in, Center distance. |
| Center to end of shaft . | 4.3100 in, 109.474 mm |
| Finish | Green |
| Gearbox component type | Gearbox |
| Horsepower rating input | 1.7500 hp, 1.305 kW |
| Horsepower rating output | 1.6300 hp, 1.215 kW |
| Housing material | Cast iron |
| Input | 56C flange |
| Input flange | 56C |
| Input HP | 1.75 |
| Input style | Quill |
| Lubrication type | PAG, standard temperatu. |
| Material | Class 30 grey iron |
| Max RPM | 350 rpm |
| Motor compatibility | NEMA motor, 56C frame |
| Mounting bolt pattern l. | 3.5000 in, 88.9 mm |
| Mounting bolt pattern w. | 2.2500 in, 57.15 mm |
| Nominal ratio | 5 |
| Output | Double solid output sha. |
| Output bore/shaft diame. | 0.75 in |
| Output horse power | 1.63 |
| Output shaft | Double (solid) |
| Output shaft center to . | 4.4000 in, 111.76 mm |
| Output style | Left, right |
| Overhung load | 710 lbf, 3158.237 N |
| Paint type | Standard |
| Paint/coating | Green |
| Rated torque output | 293 in/lb, 293.0 in/lb |
| Ratio | 5 to 1 |
| Seal type | Single-lip contact |
| Shaft diameter output | 0.7500 in, 19.05 mm |
| Shaft length output | 2.2300 in, 56.642 mm |
| Suitable for washdown | No |
| Thermal horsepower rati. | 3.3400 hp, 2.491 kW |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | MRO Supply | 141717 | 671.4 | 1 | In Stock | | Dodge | | 671.4 @ 1 |
 | Walker Industrial | 15Q05LR56 | 671.4 | 1 | In Stock | 17 | Dodge | | 671.4 @ 1 |
 | Purvis | 15Q05LR56 | 726.6 | 1 | In Stock | | Dodge | | 726.6 @ 1 |
