Marathon Electric GT1113

mpnGT1113
brandname: Marathon Electric
manufacturername: Marathon Electric

Marathon GT1113 184T Frame 184TTFC6030 TEFC General Purpose Motor, 3 Phase, Rigid Base, Ball Bearing, 5 hp, 1800 RPM, 1 Speed, 575 VAC

Brand: Marathon Electric
PartNumber: GT1113
Model: MGT1113
PackageQuantity: 1
Binding: Misc.
Manufacturer: Marathon Electric
Label: Marathon Electric

Attributes

Key	Value
Amps	5 A
Bearings	Ball
CC Number	CC003A
Duty Cycle	Continuous
Efficiency	90.2%
Enclosure Material	Iron
Enclosure Type	TEFC (Totally Enclosed .
enclosure type:	TEFC (Totally Enclosed .
Frame	184T
frame material:	Cast Iron
frame size:	184T
frequency rating:	60 Hz
Full Load Amps	5.2
full load current:	5.00 A
full load efficiency:	89.50 %
Green Certification or .	NEMA Premium(R) Rated
HP	5
Hz	60
Includes	Conduit Box
Ins. Class	F
Insulation Class	F
Inverter Rated	Yes
ip rating:	43
Item	General Purpose Motor
Length Less Shaft	13 5/16 in
Manufacturer Model #	184TTFC6030
Manufacturers Warranty .	1 yr
Max. Ambient Temp.	40 Degrees C
Maximum Ambient Tempera.	40? C
Motor Application	General Application
Motor Bearings	Ball
Motor Design	3-Phase
Motor Efficiency Group	NEMA Premium Efficient
Motor Enclosure Design	Totally Enclosed Fan-Co.
Motor Frame Material	Cast Iron
motor horsepower:	5.00 hp, 5 hp
Motor Mounting Position	Horizontal
Motor Mounting Type	Rigid Base
motor phase:	3 ph
Motor Service Factor	1.15
Motor Shaft Design	Keyed
Motor Shaft Rotation	CW/CCW
motor supply voltage:	575 V
Motor Thermal Protection	None
Mounting Orientation	Horizontal
Mounting Type	Rigid Base
mounting type:	Rigid Base
Nameplate RPM	1,765
NEMA Design	A
No. of Speeds	1
Nominal Efficiency	94.1 %
Number of Speeds	1
Overall Length	16 1/16 in, 14.8"
overall length (c-dimen.	15.81 in
Phase	3, Three
Product Type	3 Phase
Rotation	Reversible
RPM	1760
Service Factor	1.15
service factor:	1.15
Shaft Dia.	1 1/8 in
Shaft Diameter	1-1/8"
shaft diameter:	1.13 in
Shaft Length	2 3/4 in, 2.75"
Ship Weight	115 lbs.
Standards	UL Recognized (E49747),.
standards met:	UL, CSA
synchronous rpm:	1800 rpm
Usable @ 200V	No
Usable @ 208V	No
Voltage	575V AC
Volts	575
Weight	111 lb
weight:	115 lbs

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
motionindustries.com	04740232	625.01	1	In Stock		Marathon Electric		625.01 @ 1
emotorpro.com	GT1113	688.24	1	In Stock		Marathon	115.0	688.24 @ 1
grainger.ca	AOSGT1113	872.83977948	1	In Stock		MARATHON MOTORS	115.0	872.83977948 @ 1
AmazonTP	B006KM7DVG	968.1	1	In Stock	2	Marathon Electric		968.1 @ 1
