Molex 87437-1043

mpn87437-1043
brandname: Molex Incorporated
manufacturername: Molex Incorporated

MOLEX - 1.50mm Pitch Pico-SPOX Wire-to-Board Header, SMT, Vertical, Shrouded, 10 Way

Brand: Molex
PartNumber: 87437-1043
Model: 874371043
PackageQuantity: 1
Binding: Misc.
Manufacturer: Molex
Label: Molex

Attributes

Key	Value
Alternate Mfr Part Numb.	87437-1043
Applications	General Purpose, Medical
Base Product Number	087437
Category	Connectors, Interconnec.
Color	Beige
Connector	socket
Connector series	Pico-SPOX
Connector Type	Header
Contact Finish	Tin Plated
Contact Finish - Mating	Tin
Contact Finish - Post	Tin
Contact Finish Thicknes.	100.0?in (2.54?m)
Contact Finish Thicknes.	-
Contact Length - Mating	0.106" (2.70mm)
Contact Length - Post	-
Contact Material	Brass Alloy
Contact plating	tinned
Contact Plating Thickne.	2.54 ?m
Contact Shape	Square
Contact Type	Male Pin
Contacts pitch	1.5mm
Current Rating	2.5 A
Current Rating (Amps)	-
Description	CONN HEADER SMD 10POS 1.
Detailed Description	Connector Header Surfac.
Digi-Key Part Number	WM7669TR-ND - Tape & Re.
Electrical mounting	SMT
Family Name	Pico-SPOX
Fastening Type	Push-Pull
Features	-
Flammability Rating	UL 94V-0
Hole Center to Center	1.5 mm
Ingress Protection	-
Insulation Color	Beige
Insulation Height	0.199" (5.05mm)
Insulation Material	Polyamide (PA), Nylon
Kind of connector	male
Manufacturer	Molex
Manufacturer Product Nu.	0874371043
Manufacturer Standard L.	7 Weeks
Mated Stacking Heights	7.4mm
Material	Nylon
Material Flammability R.	UL94 V-0
Max. Temp.	105?C
Max. Voltage	250V AC/DC
Maximum current	2.5A
Mechanical mounting	on PCBs
Mfr	Molex
Mounting Type	Surface Mount
Number of Circuits	10
Number of Contacts	10
Number of pins	10
Number of Positions	10
Number of Positions Loa.	All
Number of Rows	1
Operating Temperature	-
Orientation	Vertical
Overall Contact Length	-
Package	Tape & Reel (TR)
Pitch	1.50 mm (0.059")
Pitch - Mating	0.059" (1.50mm)
Plating Material	Tin
Primary Type	Board Mount
Product Status	Active
Row Spacing - Mating	-
Series	Pico-SPOX 87437, 87437 .
Shrouding	Shrouded - 4 Wall
Spatial orientation	Vertical
Special Features	Not Low-Halogen
Standards	UL E29179
Style	Board to Cable/Wire
Terminal Finish	Tin Plated
Terminal Type	Surface Mount
Termination	Solder, Surface Mount
Type	Vertical Header
Type of connector	wire-board
Voltage Rating	-

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Brand	Preferred Tier
Waldom	MOLEX 87437-1043	0.35	1000	4500	MOLEX	0.35 @ 1000
TME	MX-87437-1043	0.446	1000	100	MOLEX	0.446 @ 1000
Newark	01AH8751	0.456	1000	1000	MOLEX	0.456 @ 1000
jensentools.com	10197559	0.47	1	100	Molex	0.47 @ 100
Digi-Key	717647	0.6353	1	31001	Molex	0.6353 @ 100
RS Delivers	904-8196	1.0548	1	100	Molex	1.0548 @ 100
us.rs-online.com	70793947	1.31	5	100	Molex Incorporated	1.31 @ 100
Zoro	G805890865	540.0	1	100	Molex	540.0 @ 100
