Simpson Electric 09580

mpn09580
brandname: Simpson
manufacturername: Simpson

Simpson Electric - 09580 - Analog Panel Meter, Black Spade Type Pointer, DC Voltage, 0V to 25V, Model 1227

Simpson Electric - 09580 - Analog Panel Meter, Black Spade Type Pointer, DC Voltage, 0V to 25V, Model 1227

zoom

Brand: Simpson Electric
PartNumber: 09580
PackageQuantity: 1
Manufacturer: Simpson Electric
Label: Simpson Electric

Attributes

Key	Value
(hidden) product type b.	SIMPSON ELECTRIC 09580
Accuracy	? 2% F.S. %, 2 %
Approvals	RU
Body Diameter	2.17 in.
Case Material	High Density Black Plas.
Casing Material	Plastic
Connection Type	Stud
Country of Origin (subj.	United States
Depth	1.15 in
Dimensions	2.47 L x 2.47 H in
Dimensions, Cutout, Inc.	2.22 Dia. in
Display Type	Analog
Family Series	Simpson Electric Panel .
Function	Voltmeter
Gross Weight	1 lb
Impedance	1000 Ohms?V
Input Signal	25 VDC
Item	Panel Meter Z 1227A0-25.
Item Number	09580
Manufacturer	Simpson Electric
Manufacturer Part Number	09580
Maximum Opening Tempera.	+65 ?C
Measurement Range	0 to 25 VDC
Measuring Range	0 to 25 V
Minimum Operating Tempe.	-20 ?C
Mounting Hole Diameter	0.140 in.
Movement	Annular, Self-Shielding
Net Weight	1 lb
Nominal Size	2.5 "
Operating Temperature	-4-149 ?F, -20 to +65 ?C
Panel Cut Out	2.22 in., 56.4 mm Dia.
Pointer Origin	Zero Left
Primary Type	Electromechanical
Product Header	Wide-Vue Style Analog P.
Product Series	Wide-Vue
Repeatability	0.02
Resistance	0.15 Ohms
Response Time	1.5 sec. (Max.)
Scale	0-25
Scale Legend	DC Volts
Scale Length	2.3 in.
Series	1227 Series
Special Features	Extended Operating Temp
Standards	UL Recognized
Temperature Range	-20 to 65 C
Type	Electromechanical
UPC Code	74591809580
Voltage Range	0 to 25 V
Weight	6 Oz.

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Onlinecomponents.com	09580	100.74	1	In Stock		Simpson		100.74 @ 1
	Galco	09580-SPSN	131.92	1	In Stock		Simpson Electric	1.0	131.92 @ 1
	Newark	55F1502	137.74	1	3		SIMPSON		137.74 @ 1
	Zoro	G1505911	140.79	1	In Stock	15	Simpson Electric	1.0	140.79 @ 1
	us.rs-online.com	70209362	159.46	1	1		Simpson	0.375	159.46 @ 1
