ALTech 1DU10R

B005T6ROTA

Circuit Breakers 10A D Characteristic UL 1077 1 POLE

Circuit Breakers 10A D Characteristic UL 1077 1 POLEzoom

Attributes

Key Value
Actuator TypeToggle
Alarm SwitchNo
ApprovalsUL1077 Recognized, CE, .
Auxiliary SwitchOptional
BusbarNo
CharacteristicD Curve
Current Rating10 A
Dimensions3.03 L x 0.69 W x 3.8 D.
Family SeriesAltech Circuit Breakers.
Gross Weight0.285 lbs
Instantaneous Tripping .D (10~20 In)
Interrupting (kA)5kA; 10kA with Class J .
Item Number1DU10R
kAIC @ 120 VAC10
kAIC @ 240 VAC10
kAIC @ 277 VAC10
kAIC @ 277/480 VAC10
ManufacturerAltech
Manufacturer Part Number1DU10R
Max Voltage480 VAC
Mounting35mm DIN Rail, DIN Rail
Mounting TypeDIN Rail Mount
Net Weight0.285 lbs
Neutral PoleOptional
Number of Poles1
OverloadThermal/Magnetic
Poles1
Product SeriesR
ProtectionSupplemental
Protection DegreeIP 20
Rated Current (A)10
Rated Frequency50/60 Hz
SeriesR Series
Shunt TripOptional
Special FeaturesTrip Indicator
Standards1077 Listed, IEC/EN6089.
Terminal ConfigurationBox Lugs
Terminal TypeScrew
Terminals IncludedLine and Load
TerminationScrew
Trip CurveD
Trip Time100 ms
Trip UnitFixed Thermal / Fixed M.
TypeThermal/Magnetic
UL Standard1077
Undervoltage ReleaseOptional
Voltage Rating277 VAC, 480 ; 277 V

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomSolutions Direct1DU10R10.161In StockAltech Corp.10.16 @ 1
Hawk Electronics1DU10R12.01In StockAltech12.0 @ 1
thumbzoomGalco1DU10R-ALTH13.7912In StockAltech0.28513.79 @ 12
jensentools.com1010841716.171In StockAltech16.17 @ 1
us.rs-online.com7007572217.81In StockAltech Corp17.8 @ 1
Newark95AK110719.9412In StockALTECH19.94 @ 1
AmazonSCB005T6ROTA26.981In StockALTech26.98 @ 1
thumbzoomCarlton Bates Company78039185383130.81In StockALTECH CORP130.8 @ 1
