- mpnCW201212-R47J
- brandname: Bourns
- manufacturername: Bourns
Bourns Inductor, Multilayer, 470Nh, 0.25A, 0805 - CW201212-R47J
- Brand: Bourns
- PartNumber: CW201212-R47J
- Model: CW201212-R47J
- Manufacturer: Bourns
- Label: Bourns
Attributes
| Key | Value |
|---|
| Alternate Part No. | 652-CW201212-R47J |
| Application | Mobile phones, cellular. |
| Base Part Number | CW201212 |
| Base Product Number | CW201212 |
| Brand | Bourns |
| Case Height | 1.3 mm |
| Case Length | 2.1 mm |
| Case Size | 0805 ; 2012 |
| Case Width | 1.5 mm |
| Category | Inductors, Coils, Chokes |
| Conductor Material | Enameled Copper |
| Core Material | Alumina |
| Current - Saturation (I. | - |
| Current Rating | 0.25 A |
| Current Rating (Amps) | 250 mA, 250mA |
| DC Resistance | 1.72 Ohms |
| DC Resistance (DCR) | 1.72Ohm |
| Dimensions | 0.083 L x 0.059 W x 0.0. |
| Frequency - Self Resona. | 375MHz |
| Height - Seated (Max) | 0.059" (1.50mm) |
| Inductance | 470nH, 470 nH, 0.47 ?H |
| Inductance Frequency - . | 250 MHz, 250MHz |
| Lead Free Status / RoHS. | RoHS Compliant |
| Manufacturer | Bourns |
| Manufacturer Part No. | CW201212-R47J |
| Manufacturer Part Number | CW201212-R47J |
| Manufacturer Standard L. | 14 Weeks |
| Material - Core | Ferrite |
| Maximum DC Current | 250 mA |
| Maximum DC Resistance | 1.72 Ohms |
| Maximum Operating Tempe. | +125 ?C |
| Mfr | Bourns Inc. |
| Minimum Operating Tempe. | -40 ?C |
| Mounting Type | Surface Mount |
| Operating Temperature | -40, -40?C ~ 125?C |
| Operating Temperature R. | - 40 C to + 125 C |
| Package | Tape & Reel (TR) |
| Package / Case | 0805 (2012 Metric) |
| Package/Case | 0805 (2012 Metric) |
| Packaging | Reel |
| Part # Aliases | CW201212-R47J. |
| Product Category | Fixed Inductors |
| Product Header | CW201212 Series High Q . |
| Product Status | Active |
| Q @ Freq | 33 @ 100MHz |
| Q Minimum | 33 |
| Ratings | - |
| Self Resonant Frequency | 375 MHz |
| Series | CW20 Series, CW201212 |
| Shielding | Unshielded |
| Size / Dimension | 0.083" L x 0.059" W (2.. |
| Standard Package | 2,000 |
| Supplier Device Package | 0805 (2012 Metric) |
| Terminal Electrode | Mo/Mn+Ni+Au |
| Termination | SMD |
| Termination Style | SMD/SMT |
| Test Frequency | 250 MHz |
| Tolerance | 5 %, ?5%, 0.05 |
| Type | Wirewound, High Q, Drum. |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Hotenda | H2129033 | 0.10224 | 1 | 50 | | Bourns, Inc. | | 0.10224 @ 50 |
| Onlinecomponents.com | CW201212-R47J | 0.105 | 1 | 1523 | | BOURNS | | 0.105 @ 50 |
| us.rs-online.com | 70153402 | 0.11726 | 4000 | 50 | | Bourns | | 0.11726 @ 4000 |
| iodParts | CW201212-R47J | 0.128 | 2000 | 4000 | | Bourns | | 0.128 @ 2000 |
 | Newark | 44AC1930 | 0.17 | 4000 | 50 | | BOURNS | | 0.17 @ 4000 |
| Digi-Key | 419167 | 0.2666 | 1 | 50 | | Bourns Inc. | | 0.2666 @ 50 |
 | swatee.com | CW201212-R47J | 0.468 | 1 | 262 | | Bourns | | 0.468 @ 50 |
| AmazonSC | B07TDTK8MR | 72.6 | 1 | 50 | | BOURNS | | 72.6 @ 50 |
