- mpnU3P1D
- brandname: US Motors
- manufacturername: US Motors
3 HP
- Brand: US Motors
- PartNumber: U3P1D
- PackageQuantity: 1
- Binding: Tools & Home Improvement
- Manufacturer: Nidec Motor Corporation
- Label: Nidec Motor Corporation
Attributes
| Key | Value |
|---|
| Brand | U.s. Motors |
| Composition | Aluminum |
| Construction | Aluminum |
| Drive End Flange Type | Standard |
| Enclosure | TEFC, Totally Enclosed . |
| Estimated Weight | 66.00 |
| Family Series | US Motors Motors |
| FL Amps | 8.4-7.8/3.9 |
| FL Efficiency | 87.5 |
| Frame | 182T |
| Frequency | 60 Hz |
| Full Load Current | 8.4-7.8 A, 3.9 A |
| Gross Weight | 60 lbs |
| Hertz | 50, 60 |
| Horsepower | 3 hp |
| HP | 3 |
| International Shipping | No |
| Item | General Purpose Motor |
| Item Number | U3P1D |
| Kilowatts | 2.2 kW |
| Length Less Shaft | 13 3/8 in |
| Manufacturer | US Motors (Nidec), US M. |
| Manufacturer Part Number | U3P1D |
| Manufacturers Warranty . | 2 yr |
| Model Number | A430 |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Fan-Co. |
| Motor Frame Material | Cast Aluminum |
| Motor Mounting Position | Horizontal or Vertical . |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.25 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Mounting | Foot Mount |
| Mounting Type | Foot Mount |
| Mpn | U3P1D |
| Nameplate RPM | 3,600 |
| NEMA Frame | 182T |
| Net Weight | 0 lbs |
| Nominal Voltage | 208 VAC, 240 VAC, 480 V. |
| Number of Poles | 2 |
| Number of Speeds | 1 |
| Overall Length | 16 1/4 in |
| Part Number | U3P1D |
| Phase | 3 |
| Product Type | General Purpose |
| RPM | 3,540 RPM |
| RPM Range | 3,001-3,600 |
| Shaft Dia. | 1 1/8 in |
| Shaft Length | 2 3/4 in |
| SKU | ZO-G4562257 |
| Speed (RPM) | 3540 |
| Standards | CE, CSA, UL |
| SubCategory | Motors/Ac Motors |
| Type | General Purpose |
| Voltage | 190V, 230V, 380V, 460V,. |
| Voltage (AC) | 208-230 VAC, 460 VAC |
| Voltage Compatibility | 200-230/440V AC, 200-23. |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Global Industrial | WBB466325 | 599.0 | 1 | In Stock | | US Motors | | 599.0 @ 1 |
 | Galco | U3P1D-USM | 618.18 | 1 | In Stock | | US Motors | 60.0 | 618.18 @ 1 |
 | Zoro | G4562257 | 621.08 | 1 | In Stock | | U.S. Motors | 55.6 | 621.08 @ 1 |
 | motorsandcontrol.com | U3P1D | 637.2 | 1 | In Stock | | US Motors (Nidec) | 66.0 | 637.2 @ 1 |
 | National Supply Network | B466325 | 648.33 | 1 | In Stock | | US MOTORS | | 648.33 @ 1 |
 | simsupply.com | ZO-G4562257 | 720.51 | 1 | In Stock | | U.s. Motors | | 720.51 @ 1 |
 | motionindustries.com | 00545436 | 829.92 | 1 | In Stock | | US Motors (Nidec) | | 829.92 @ 1 |
 | sustainablesupply.com | C2828753 | 863.52 | 1 | In Stock | | US Motors | 55.6 | 863.52 @ 1 |
| uri.com | U3P1D | 1626.46 | 1 | In Stock | | U.S. Motors | 55.0 | 1626.46 @ 1 |
