- mpn15QZ05R56
- brandname: Dodge
- manufacturername: Dodge
DODGE 15QZ05R56 1.75HP 5:1 56C GEAR REDUCER D244091
- Brand: Dodge
- PartNumber: D244091-15QZ05R56
- PackageQuantity: 1
- Manufacturer: DODGE
- Label: DODGE
Attributes
| Key | Value |
|---|
| Base to output center h. | 1.8700 in, 47.498 mm |
| Case size | 15 |
| Center distance (in) | 1.5 in, Center distance. |
| center distance: | 1.50 in |
| Center to end of shaft . | 4.3100 in, 109.474 mm |
| Finish | Silver-gray epoxy |
| Gearbox component type | Gearbox |
| Horsepower rating input | 1.7500 hp, 1.305 kW |
| Horsepower rating output | 1.6300 hp, 1.215 kW |
| housing dimensions: | 7.09 x 4 x 6.63 in |
| housing height: | 6.63 in |
| housing length: | 7.09 in |
| Housing material | Cast iron |
| housing material: | Cast iron |
| housing width: | 4.00 in |
| Input | 56C flange |
| Input flange | 56C |
| Input HP | 1.75 |
| Input style | Quill |
| input type: | C-Face Quill |
| Lubrication type | PAG, standard temperatu. |
| manufacturer reducer si. | 15 |
| Material | Class 30 grey iron |
| Max RPM | 350 rpm |
| maximum input horsepowe. | 1.320 hp @ 1750 rpm |
| maximum output rpm: | 350.000 @ 1750 rpm input |
| maximum output torque: | 293 in-lbs @ 1750 rpm |
| Motor compatibility | NEMA motor, 56C frame |
| Mounting bolt pattern l. | 3.5000 in, 88.9 mm |
| Mounting bolt pattern w. | 2.2500 in, 57.15 mm |
| mounting type: | No Base |
| nema / iec frame size: | 56C |
| Nominal ratio | 5 |
| Output | Right side solid output. |
| Output bore/shaft diame. | 0.75 in |
| output direction: | Right Hand |
| Output horse power | 1.63 |
| Output shaft | Right (solid B) |
| Output shaft center to . | 4.4000 in, 111.76 mm |
| output size: | 0.7500 in |
| Output style | Right |
| output type: | Solid Shaft |
| Overhung load | 710 lbf, 3158.237 N |
| overhung load capacity: | 710 lb |
| Paint type | Stainless epoxy |
| Paint/coating | Green |
| Rated torque output | 293 in/lb, 293.0 in/lb |
| Ratio | 5 to 1 |
| ratio: | 5:1 |
| reduction: | Single |
| Seal type | Two-piece harsh duty |
| Shaft diameter output | 0.7500 in, 19.05 mm |
| Shaft length output | 2.2300 in, 56.642 mm |
| Suitable for washdown | Yes |
| Thermal horsepower rati. | 3.3400 hp, 2.491 kW |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Walker Industrial | 15QZ05R56 | 785.09 | 1 | In Stock | 10 | Dodge | | 785.09 @ 1 |
 | motionindustries.com | 02767565 | 876.73 | 1 | In Stock | | Dodge | | 876.73 @ 1 |
 | MRO Supply | 144288 | 889.43 | 1 | In Stock | | Dodge | | 889.43 @ 1 |
 | Purvis | 15QZ05R56 | 963.26 | 1 | In Stock | | Dodge | | 963.26 @ 1 |
