Walter AG F4042.Z20.022.Z03.08

B00IRZIW6O

Walter AG - F4042.Z20.022.Z03.08 - Indexable Square Shoulder End Mill, Max. Cutting Dia. 22 mm, Shank Dia. 20.00 mm, Straight

Walter AG - F4042.Z20.022.Z03.08 - Indexable Square Shoulder End Mill, Max. Cutting Dia. 22 mm, Shank Dia. 20.00 mm, Straightzoom

Attributes

Key Value
ANSI CodeF4042.Z20.022.Z03.08
Bore0.866"
Compatible HardwareFS1454 T8IP Clamping Sc.
Coolant FedCoolant Through
Country of Origin (subj.Germany
Cutter Dia.0.866"
Cutting ApplicationCircular Interpolation .
Cutting Edge TypeCarbide
Cutting Length0.315"
Depth of Cut8.00mm
Diameter0.866"
Features2 Cutting Edges per Ind.
Head Projection Length39.00mm
Insert Cutting Edge Len.8.00mm
Insert ScrewFS359 Torx 15
ISO NumberF4042.Z20.022.Z03.08
ItemIndexable Square Should.
Left/Right HandRight
MaterialAll ISO
Max. Cutting Dia.22 mm
Max. Speed6,900 RPM
Min. Cutting Dia.22.00mm
NomenclatureF4042.Z20.022.Z03.08
Number of Coolant Holes2
Number of Inserts3
Number of Inserts Requi.3
Overall Length200.00mm
Overall Length (In.)7.874
SeriesF4042
Shank Dia.20.00mm
Shank Dia. (In.)0.787
Shank Type - MachiningStraight

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG8269292417.01In StockWalter1.5417.0 @ 1
thumbzoomRaptor SuppliesAD6DJL582.6756781In StockWALTER582.675678 @ 1
