Schneider Electric LADR0

B001UHKRPK

SCHNEIDER ELECTRIC LADR0 model Name 0.10 Sec. To 3.00 Sec. Off Delay Iec Timer Module

SCHNEIDER ELECTRIC LADR0 model Name 0.10 Sec. To 3.00 Sec. Off Delay Iec Timer Modulezoom

Attributes

Key Value
[Ith] Conventional Free.10 A 60?C
[Ui] Rated Insulation V.690 V IEC 60947-5-1 || .
Adjustment OperatorKnob
Ambient Air Temperature.-40-70?C
ApplicationTeSys D CAD;TeSys D LC1.
ApprovalsCSA, UL
Auxiliary Contacts Oper.time delay
BrandSchneider Electric
Catalog NumberLADR0
Coil Voltage690 VAC, 690 V AC 25....
ComponentAuxiliary Contact Block
Connectionscrew clamp terminals 1.
Connections - Terminalsscrew clamp terminals 1.
Contact Configuration1 NO + 1 NC;Time delay
Contact Current Rating10 A
Contact Operation1NO/1NC
Contact Rating10 A 60 A Degrees C
Contacts1NO, 1NC
Contacts Normally Closed1
Contacts Normally Open1
Control Voltage24
Country of OriginFR - France, France
Current Stock9
Delay TypeOff Delay
Depth61 mm
ECCNEAR99
Family NameTeSys Family
Family SeriesSquare D Relays
Gross Weight0.155 lbs
Height48 mm
International ShippingNo
Ip Degree Of ProtectionIP20 conforming to IEC .
Irms Rated Making Capac.140 A AC IEC 60947-5-1 .
ItemIEC Timer Module
Item NumberLADR0
Item TypeTime Delay Auxiliary Co.
Lead TimeExpected to ship in 1-2.
Made in USANo
ManufacturerSquare D, Schneider Ele.
Manufacturer Part Number494946
Max Time3 s
Max. Contact Blocks (No.1
Mode of OperationOff Delay
MountingFront, Clip
Mounting TypeSurface
MpnLADR0
Multi-FunctionNo
Net Weight0.14 lbs
Nominal Coil Voltage690 VAC
Non-Overlap Time1.5 ms on de-energisati.
Number of Contacts2
Number of Poles2
Operating Temperature-5-60 A Degrees C
Protective TreatmentTH IEC 60068
RangeTeSys || TeSys Deca
Range CompatibilityTeSys D CAD || TeSys D .
Range of Time Delay0.10 sec to 3.00 sec
SeriesTeSys D, TeSys Deca Ser.
Size2.40
SKUZO-G1765897
Special FeaturesNORMAL ENVIRONMENT
StandardIECEE CB Scheme;UL;CSA;.
StandardsEN/IEC 60947-5-1 || UL .
Starter Actionstime delay
Starter Amperage10 Amp
Starter Auxiliary Conta.1 NO + 1 NC
Status IndicatorNone
Sub BrandTeSys D;TeSys Deca
Sub ComponentTime Delay Auxiliary Co.
SubCategoryElectrical
TerminationScrew Terminals
Time Delay Range0.3...3 s
Time Range (Seconds)0.1-3
Time Range AdjustmentOnboard
Timing Range0
UNSPSC39121529
UPC785901213857
UPC Code785901213857
Use WithTeSys D and F
Voltage (AC)690 VAC
Warranty DescriptionContractual Warranty:18.
Width44 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomTMELADR057.91122SCHNEIDER ELECTRIC57.91 @ 1
thumbzoomkempstoncontrols.co.ukLADR075.71163612Schneider75.711636 @ 1
RS Delivers394-9863117.336113Schneider Electric117.336 @ 1
AmazonSCB0784YBPNY120.01In StockSchneider Electric120.0 @ 1
thumbzoomblackhawksupply.comLADR0136.011In StockSquare D136.01 @ 1
thumbzoomZoroG1765897157.99130Schneider Electric0.17157.99 @ 1
AmazonTPB0784YBPNY159.241In Stock5SCHNEIDER ELECTRIC159.24 @ 1
thumbzoomNewark79C9281160.881In StockSCHNEIDER ELECTRIC160.88 @ 1
thumbzoomgordonelectricsupply.comLADR0162.091In Stock10SQUARE D162.09 @ 1
thumbzoomGalcoLADR0-SQD164.3112Square D0.155164.31 @ 1
us.rs-online.com70379254165.2614Schneider Electric165.26 @ 1
thumbzoomsustainablesupply.comC1193152171.01In StockSchneider Electric0.17171.0 @ 1
thumbzoommidwestapplianceparts.comLADR0-SQ-P185.991In StockSquared185.99 @ 1
thumbzoomsimsupply.comZO-G1765897187.0719Schneider Electric187.07 @ 1
rspsupply.comSCHNEIDER LADR0193.441In StockSchneider Electric193.44 @ 1
Graybar22052175199.7521In StockSquare D (Schneider Electric)199.752 @ 1
thumbzoomNational Supply Network69663920200.181In StockSchneider Electric200.18 @ 1
thumbzoomcrescentelectric.com149600215.02132Schneider Electric215.02 @ 1
thumbzoomRaptor SuppliesAG6PLE289.840591In StockSCHNEIDER ELECTRIC289.84059 @ 1
