Rexnord ZAS3315F

B00BJP3TEE

Rexnord ZAS3315F Spherical Pillow Block Roller Bearing, 4-Bolt Pillow Block, Eccentric Locking Collar, Clearance Seals, Expansion Type, Cast Iron, 3-15/16" Shaft, 4-1/4" Base To Center, 12-1/2" Bolt Centers

Rexnord ZAS3315F Spherical Pillow Block Roller Bearing, 4-Bolt Pillow Block, Eccentric Locking Collar, Clearance Seals, Expansion Type, Cast Iron, 3-15/16" Shaft, 4-1/4" Base To Center, 12-1/2" Bolt Centerszoom

Attributes

Key Value
Actual Bolt Center to C.12.5 Inch | 317.5Millim.
base to bore centerline:4.2500 in
Base to Center Height4.25 Inch | 107.95 Mill.
base width:4-1/2 in
bearing type:Spherical Roller
bolt center-to-center l.12-1/2 in
Bolt Spacing Maximum0 Inch | 0Millimeter
Bolt Spacing Minimum0 Inch | 0Millimeter
bore type:Round
BrandREXNORD
CategoryPillow Block Bearings
Expansion / Non-expansi.Expansion
expansion type:Expansion Bearing (Floa.
finish/coating:Powder Coated
Global Part Number GPN502169
Harmonized Tariff Code8483.20.40.80
Housing Configuration1 Piece Solid
housing construction:Solid Pillow Block
Housing MaterialCast Iron
housing material:Cast Iron
Housing Style4 Bolt Pillow Block
Inch - MetricInch
Insert Part Number3315U
Length Thru Bore5.188 Inch | 131.775 Mi.
locking device:Eccentric Collar
lubrication type:Lubrication Fitting
Manufacturer NameREXNORD
maximum rpm:2050 RPM
Mounting Bolts3/4 Inch
Mounting MethodEccentric Collar
mounting:Four-Bolt Base
Nominal Bolt Center to .12.5 Inch | 317.5 Milli.
Number of Mounting Holes4
Other FeaturesDouble Row
overall width:5-3/16 in
price$ 2,110.38 / each
radial dynamic load cap.118000 lb
radial static load capa.127500 lb
RelubricatableYes
seal type:Clearance/Non-Contact
SealsClearance Seal
series:3000
standards met:ANSI/ABMA STD 9-1990
titleZAS3315F
UNSPSC31171511
Weight / LBS61

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomMRO Supply5072601756.51In Stock14Rexnord61.01756.5 @ 1
thumbzoomLily BearingZAS3315F1793.821In StockREXNORD61.01793.82 @ 1
thumbzoomRadwellZAS3315F2550.01In StockREXNORD2550.0 @ 1
thumbzoommotionindustries.com006009032647.211In StockRexnord2647.21 @ 1
