Square D QOB1251021

B007SPIWYG

Square D - QOB1251021 - Circuit Breaker, Bolt-On, 1 Pole, 25A

Square D - QOB1251021 - Circuit Breaker, Bolt-On, 1 Pole, 25Azoom

Attributes

Key Value
[Ue] Rated Operational .120/240 V AC || 120 V A.
AC Voltage Rating120/240V AC
Accessory / Separate Pa.shunt trip 120/208/240 .
Ambient Air Temperature.40 ?C
Amperage Rating25
Amps25 A
ApplicationHACR rated
Awg GaugeAWG 14...AWG 8 copper o.
AWG RangeAWG 14...AWG 8 copper o.
BrandSquare D
Breaking Capacity10 kA 120/240 V AC 50/6.
Catalog NumberQOB1251021
China Rohs RegulationProduct out of China Ro.
Circuit Breaker ActuatorPaddle
Circuit Breaker Applica.HACR rated
Circuit Breaker Mountin.Bolt On
Circuit Breaker TypeShunt Trip, standard
Compatible Panelboard/L.QO
ConnectionPressure plate;AWG 14...
Country of OriginMX - Mexico, Mexico
Country of Origin (subj.Multiple
Current Rating25A
DC Voltage Rating48V DC
Depth2.91 in, 74 mm
DisplayQOB1251021 Mini Circuit.
ECCNEAR99
Electrical ConnectionPressure Plate
Eu Rohs DirectiveCompliant
For Use WithSquare D NQOD Panelboar.
Frame Size100A/QO
GTIN00785901729280
Halogen Content Perform.Halogen free product
Height76 mm, 2.99
Interrupt Rating10 kA, 10?kA 120/240 V .
ItemMiniature Circuit Break.
Item TypeShunt trip 120/208/240 .
Length3.0 in, 2.91
Length (Straight Wirewa.3.0 in
Length UOMInch
Line Rated Current25 A
Made in USANo
ManufacturerSchneider Electric
MaterialFIBERGLASS FILLED THERM.
Max. AIR Rating10kA at 120/240V AC
Max. Operating Temp.104 Degrees F
Max. Wire Size8 AWG
Mercury FreeYes
Min. Operating Temp.104 Degrees F
Min. Wire Size14 AWG
MountingBolt On
Mounting Modebolt-on
Mounting Typebolt-on
Net Weight0.299 kg
No. of Poles1-Pole
Number of Poles1
Number Of Spaces Requir.2
Operating TemperatureCALIBRATED FOR USE AT 4.
Phase1, Single
Poles Description1P
Product CertificationsUL Listed || CSA
Product Or Component Ty.miniature circuit-break.
Product TypeMiniature Circuit Break.
Promotion RestrictionNot eligible for promot.
Range Of ProductQO
Rated Voltage120/240V AC || 120V AC .
Reach RegulationReference contains Subs.
Rohs Exemption Informat.Yes
SeriesQOB
Special FeaturesSTANDARD BOLT-ON
StandardUL LISTED - CSA CERTIFI.
StandardsCSA, UL Listed
Sub BrandQO
Sustainable Offer StatusGreen Premium product
Terminal ConnectionPressure Plate
Tightening Torque5-5 N.m 10-25 mm? (AWG .
Torque5-5 N.m 10-25 mm? (AWG .
Toxic Heavy Metal FreeYes
UNSPSC39121603
UPC785901729280
Voltage Rating120/240 V AC;120 V AC
Warranty18 months
Warranty DescriptionContractual Warranty:18.
Width1.5 in, 38 mm, 1.5

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG0997805201.01In Stock26Square D0.63201.0 @ 1
thumbzoomRadwellQOB1251021210.01In StockSCHNEIDER ELECTRIC SQUARE D210.0 @ 1
thumbzoommayerelectric.comSQDQOB1251021219.191In StockSQUARE D0.6578219.19 @ 1
us.rs-online.com72131729221.41In StockSquare D221.4 @ 1
Newark80C3579245.491In StockSQUARE D BY SCHNEIDER ELECTRIC245.49 @ 1
AmazonTPB007SPIWYG260.181In Stock5Square D260.18 @ 1
thumbzoomsustainablesupply.comC1179613262.081In StockSquare D0.63262.08 @ 1
thumbzoomcrescentelectric.com77372268.6711Square D268.67 @ 1
Graybar92104863348.19681In StockSquare D (Schneider Electric)348.1968 @ 1
thumbzoomRaptor SuppliesAF9GTF440.23591In StockSQUARE D440.2359 @ 1
