Leeson 192206.00

B00EP3C8YY

Leeson 192206.00 Rigid Base IEC Metric Motor, 3 Phase, D90L Frame, B3 Mounting, 2HP, 1800 RPM, 230/460V Voltage, 60/50Hz Fequency

Leeson 192206.00 Rigid Base IEC Metric Motor, 3 Phase, D90L Frame, B3 Mounting, 2HP, 1800 RPM, 230/460V Voltage, 60/50Hz Fequencyzoom

Attributes

Key Value
Amperage Rating5.4/2.7 A
ApprovalsCSA, UL
Bearing TypeBall, 12.6
CategoryElectric Motor
Class/GroupC90T17FZ17
CompositionAluminum
Description:Replaced by 090LT17FH65.
Dimensions12.83 in L
Efficiency %87.5 %
EnclosureTEFC, Totally Enclosed .
Enclosure TypeTotally Enclosed Fan Co.
Family SeriesLeeson Motors, IEC Seri.
FrameD90LD, 90L
Frequency Rating60 Hz
Gross Weight0 lbs
Horsepower2 hp
HP2
IEC FrameD90LD
Insulation ClassClass F
Item ConditionFACTORY NEW
Item Number192206.00
Kilowatts1.5 kW
ManufacturerLEESON ELECTRIC CORPORA.
Manufacturer Part Number192206.00
MaterialAluminum
MFG Part #:192206.00
Model NumberC90T17FZ17
mountingRigid Base
Mounting TypeB3 Flange/Rigid Base, F.
Net Weight38 lbs
Nominal Voltage240 VAC, 480 VAC
Number of Poles4
Number of Speeds1
Overall Length12.6 "
Phase3, 3 ph
Product SeriesIEC
RotationReversible
RPM1,800 RPM, 1800
Service Factor1.15
Shaft DiameterUL;CSA
Shaft Size1 in Dia x 1.96 in L
Special FeaturesIEC Metric Motors
Speed1745 rpm
Supplier:LEESON ELECTRIC CORPORA.
UPC:691720246924
Volts230/460

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
kscdirect.comLEE 192206.00232.171In StockLEESON ELECTRIC CORPORATION232.17 @ 1
us.rs-online.com72637903244.651In StockLeeson244.65 @ 1
thumbzoomWalker Industrial192206-00265.031In Stock10Leeson265.03 @ 1
thumbzoomcbtcompany.com192206.00282.891In StockLeeson Electric282.89 @ 1
thumbzoomGalco192206.00-LEES318.041In StockLeeson38.0318.04 @ 1
thumbzoomelectricmotorwholesale.com192206354.01In StockLEESON354.0 @ 1
thumbzoomDealers Electric192206.00467.841In StockLeeson46.0467.84 @ 1
AmazonTPB007ICO7W0529.81In Stock10Leeson529.8 @ 1
thumbzoomPurvis192206LEE735.91In StockLEESON735.9 @ 1
thumbzoomRaptor SuppliesAJ2TTH1040.3198911In StockLEESON1040.319891 @ 1
