Rexnord ZAS6315

B00BJP0XHK

Rexnord ZAS6315 Shurlok Adapter Spherical Mounted Pillow Block, 2-Bolt Pillow Block, Adapter Mounted, Clearance Seals, Expansion Type, Cast Iron, 3-15/16" Shaft, 4-1/8" Base To Center, 10-7/8" Bolt Centers

Rexnord ZAS6315 Shurlok Adapter Spherical Mounted Pillow Block, 2-Bolt Pillow Block, Adapter Mounted, Clearance Seals, Expansion Type, Cast Iron, 3-15/16" Shaft, 4-1/8" Base To Center, 10-7/8" Bolt Centerszoom

Attributes

Key Value
Actual Bolt Center to C.10.9 Inch | 276.2Millim.
base to bore centerline:4.1250 in
Base to Center Height4.125 Inch | 104.775 Mi.
base width:4-1/8 in
bearing type:Spherical Roller
bolt center-to-center l.10-7/8 in
Bolt Spacing Maximum0 Inch | 0Millimeter
Bolt Spacing Minimum0 Inch | 0Millimeter
bore type:Round
BrandREXNORD
CategoryPillow Block Bearings
Expansion / Non-expansi.Expansion
expansion type:Expansion Bearing (Floa.
finish/coating:Powder Coated
Global Part Number GPN502161
Harmonized Tariff Code8483.20.40.80
Housing Configuration1 Piece Solid
housing construction:Solid Pillow Block
Housing MaterialCast Iron
housing material:Cast Iron
Housing Style2 Bolt Pillow Block
Inch - MetricInch
Insert Part Number6315U
Length Thru Bore5.969 Inch | 151.613 Mi.
locking device:Adapter Mount
lubrication type:Lubrication Fitting
Manufacturer NameREXNORD
maximum rpm:2050 RPM
Mounting Bolts1 Inch
Mounting MethodTapered Adapter Sleeve
mounting:Two-Bolt Base
Nominal Bolt Center to .10.9 Inch | 276.9 Milli.
Number of Mounting Holes2
Other FeaturesDouble Row
overall width:5-31/32 in
price$ 2,154.84 / each
radial dynamic load cap.118000 lb
radial static load capa.127500 lb
RelubricatableYes
seal type:Clearance/Non-Contact
SealsClearance Seal
series:6000
standards met:ANSI/ABMA STD 9-1990
titleZAS6315
UNSPSC31171511
Weight / LBS56

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomLily BearingZAS63151831.611In StockREXNORD56.01831.61 @ 1
thumbzoomMRO Supply5072971936.991In Stock14Rexnord56.01936.99 @ 1
thumbzoomRadwellZAS63152850.01In StockREXNORD2850.0 @ 1
thumbzoommotionindustries.com034722732919.221In StockRexnord2919.22 @ 1
