AO Smith 9637

mpn9637
brandname: Century
manufacturername: Century

AO Smith 9637 5.0-Inch Frame Diameter 1/6 HP 1050 RPM 230-Volt 2.9-Amp Sleeve Bearing Fan Coil

AO Smith 9637 5.0-Inch Frame Diameter 1/6 HP 1050 RPM 230-Volt 2.9-Amp Sleeve Bearing Fan Coil

zoom

Brand: AO Smith
PartNumber: 9637
Model: 9637
PackageQuantity: 1
Binding: Tools & Home Improvement
Manufacturer: Century Electric/AO Smith Motors Co
Label: Century Electric/AO Smith Motors Co

Attributes

Key	Value
9637 is listed in Centu.	A.O. Smith DA3J092, Day.
Amps	2.9
Bearings	Sleeve
Body Dia.	5 in
Capacitor Required	No
Country of Origin (subj.	Mexico
Duty	Continuous
Duty Cycle	Continuous
Enclosure Type	ODP (Open Dripproof)
Frame	42Y
Full Load Amps	2.1
HP	1/6
Hz	60, 60 Hz
Includes	Resilient Base
Ins. Class	A
Insulation Class	A
Item	Room Air Conditioner Mo.
Lead Length	36 in
Length Less Shaft	5 3/16 in
Max. Ambient Temp.	40 Degrees C
Maximum Ambient Tempera.	40? C
Motor Application	HVAC/R
Motor Bearings	Sleeve
Motor Design	Shaded Pole
Motor Diameter	5"
Motor Enclosure Design	Open Dripproof
Motor Frame Material	Steel
Motor Mounting Position	Horizontal
Motor Mounting Type	Cradle Base
Motor Service Factor	1
Motor Shaft Design	Flat
Motor Shaft Rotation	CCWLE
Motor Sub Application	Room Air Conditioner
Motor Thermal Protection	Auto
Mounting	Cradle
Mounting Holes	4
Nameplate RPM	1,050 RPM
No. of Speeds	1
Number of Shafts	2
Number of Speeds	1
Overall Length	21 1/4 in
Phase	1, Single
Product Type	Shaded Pole
Resilient Ring Dia.	2 1/2 in
Ring to Ring Center	4 3/4 in
Rotation	Double Shafted
RPM	1050
RPM Range	1,001-1,100
Service Factor (SF)	1.00
Shaft Dia.	1/2 in
Shaft Diameter	1/2"
Shaft Length	8-1/2" x 8-1/2", 8 1/2 .
Ship Weight	13 lbs.
Standards	CSA Certified, UL Recog.
Stud Quantity	4
Thermal Protection	Automatic
Usable @ 200V	No
Usable @ 208V	No
Voltage	230V AC
Voltage Compatibility	115/200-230V AC, 115/20.
Volts	230
Weight	13 lb

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	emotorpro.com	9637	184.7	1	In Stock		Century	13.0	184.7 @ 1
	Zoro	G1938851	191.73	1	In Stock		Century	13.0	191.73 @ 1
	midwestapplianceparts.com	9637-AO-P	207.07	1	In Stock		AO Smith		207.07 @ 1
	sustainablesupply.com	C2090736	290.96	1	In Stock		Century	15.0	290.96 @ 1
	Raptor Supplies	AD8RRQ	363.764466	1	In Stock		CENTURY		363.764466 @ 1
