MNG14-10FFBK

mpnMNG14-10FFBK
brandname: 3-M
manufacturername: 3-M

3M(TM) Scotchlok(TM) Flanged Block Fork, Nylon Insulated w/Insulation Grip MNG14-10FFBK, 16-14 AWG

PartNumber: MNG14-10FFBK
PackageQuantity: 1000
Manufacturer: 3M
Label: 3M

Attributes

Key	Value
3M Number	MNG14-10FFBK
Barrel Length	0.25 in, 0.46 in
Barrel Length Type	Butted
Barrel Style	Insulation Grip
Base Product Number	MNG14
Brand	3M
Category	Electrical Insulating T.
Clearance	0.25 in
Color	Blue, Yellow
Connection Material	Copper
Connection Type	Crimp
Contact Finish	Tin
Contact Material	Copper, ETP
Country of Origin	USA
Fastening Mechanism	Locking
Features	-
For Wire Size	14 AWG, 16 AWG
Fork Width	0.3 in
Inside Diameter	0.09 in
Insulation	Insulated
Insulation Color	Blue
Insulation Diameter	0.170" (4.32mm)
Insulation Length	0.71 in
Insulation Material	Nylon
Insulation Type	Nylon
International Shipping	No
Item	Fork Terminal
Length - Overall	0.860" (21.84mm)
Length - Ring Center to.	0.250" (6.35mm)
Length - Termination	0.460" (11.68mm)
Manufacturer	3M
Material	Nylon
Material - Insulation	Polyamide (PA), Nylon
Max. Temp.	221 Degrees F
Max. Voltage	600 V
Maximum Insulation Outs.	0.17 in
Maximum Wire Size	14 AWG
Mfr	3M
Minimum Conductor Leg D.	16 AWG
Minimum Wire Size	16 AWG
Mounting Type	Free Hanging (In-Line)
Mpn	MNG14-10FFBK
Overall Length	0.86 in
Overall Width	0.3 in
Package	Bulk
Package Quantity	1000 per case
Part Status	Active
Seam	Brazed
Seam Style	Butted
Series	Scotchlok?
SKU	ZO-G5499462
Standards	CSA Certified, UL Listed
Stud Size	#10
Stud/Tab Size	10 Stud
SubCategory	Electrical
Terminal Connection	Crimp
Terminal Type	Flanged, Flanged Block
Termination	Crimp
Termination Style	Crimp
Tongue Inside Opening	-
Tongue Width	0.3 in
Tongue Width - Wire Con.	0.3 in
Trade Name	Scotchlok
Type	Insulated, Block Fork
UNSPSC	31201502
UPC	054007016311, 005400701.
Width - Outer Edges	0.300" (7.62mm)
Wire Gauge	14-16 AWG
Wire Range	16 to 14 AWG
Wire Size Range	16 AWG - 14 AWG

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
Onlinecomponents.com	MNG14-10FFBK	0.279	30	1000		3M		0.279 @ 1000
Digi-Key	3865642	0.44618	1000	1000		3M		0.44618 @ 1000
turtle.com	MMM MNG14-10FFBK	0.47	1	1000		3M		0.47 @ 1000
Platt.com	0318801	0.57	1	1000		3M		0.57 @ 1000
rshughes.com	054007-01631	380.0	1000	1000		3M		380.0 @ 1000
gordonelectricsupply.com	MNG14-10FFBK	393.0	1	1000	455	3-M		393.0 @ 1000
Dale-Electric	MNG14-10FFBK	434.28	1	1000		3M		434.28 @ 1000
Zoro	G5499462	449.99	1	1000		3M	2.51	449.99 @ 1000
simsupply.com	ZO-G5499462	497.7	1	1000		3M		497.7 @ 1000
sustainablesupply.com	C1178343	621.57	1	1000		3M	2.51	621.57 @ 1000
Raptor Supplies	AB9LBB	1034.599059	1	1000		3M		1034.599059 @ 1000
