ASEA BROWN BOVERI ST203M-C16

mpnST203M-C16
brandname: ABB
manufacturername: ABB

Circuit Breaker; Miniature; DIN Rail Mount; C Curve; 3 Pole; 16A, ST203M-C16

Circuit Breaker; Miniature; DIN Rail Mount; C Curve; 3 Pole; 16A, ST203M-C16

zoom

Brand: ASEA BROWN BOVERI
PartNumber: ST203M-C16
Manufacturer: ABB
Label: ABB

Attributes

Key	Value
AC Voltage Rating	277/480V AC
Alarm Switch	Optional
Amps	16 A, 16
Application	Commercial, Industrial,.
Approvals	UL 1077 ; CSA 22.2 No. .
Auxiliary Switch	Optional
Breaker Series	ST200M
Busbar	Optional
Characteristic	C Curve
Circuit Breaker Actuator	Toggle
Circuit Breaker Mountin.	DIN Rail
Country of Origin (subj.	Hungary
CSA Standard	22.2
Current Rating	16 A
Curve Type	C
DC Voltage Rating	110V DC
Depth	3.0 in
Estimated Weight	0.79
Family Series	ABB Circuit Breakers, S.
Gross Weight	0.815 lbs
IEC Standard	60947-2
Interrupt Rating AC	10 kA
Item	IEC Supplementary Prote.
Item Number	ST203M-C16
kA Rating	10
kAIC @ 125 VDC	10
kAIC @ 240 VAC	10
kAIC @ 277 VAC	5
kAIC @ 480 VAC	10
kAIC @ 60 VDC	10
Length	3.38 in
Length (Straight Wirewa.	3.38 in
Manufacturer	ABB
Manufacturer Part Number	ST203M-C16
Max Voltage	125 VDC, 277/480 VAC
Max. AIR Rating	10kA at 277/480V AC
Max. Wire Size	4 AWG
Meets UL Type	UL 1077
Min. Wire Size	14 AWG
Mounting	DIN Rail
Mounting Type	DIN Rail Mount
Net Weight	0.765 lbs
Neutral Pole	No
Number of Poles	3
Part Number	ST203M-C16
Phase	3
Poles	3
Product Series	ST200M
Protection	Supplemental
RoHS	Yes
Series	ST200 M Series, EP100
Shunt Trip	Optional
Standards	UL1077/CSA 22.2 No. 235.
Terminal Connection	Screw Clamp
Terminal Type	Screw
Terminals Included	Line and Load
Termination	Screw
Trip Curve	C
Trip Type	Thermal Magnetic
Trip Unit	Fixed Thermal / Fixed M.
Type	Thermal/Magnetic, Trip .
UL Rating	UL 1077
UL Standard	1077
Undervoltage Release	Optional
UPC Code	4016779023924
Voltage	277VAC, 480VAC
Voltage Rating	480 ; 480 ; 277 V
Volts AC	277, 480Y
Width	2.13 in

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	standardelectricsupply.com	2357771	96.01	1	In Stock		ABB		96.01 @ 1
	Walker Industrial	ST203M-C16	96.5	1	In Stock	17	ABB		96.5 @ 1
	Airline Hydraulics	ABB ST203M-C16	100.32	1	In Stock		ABB		100.32 @ 1
	motorsandcontrol.com	ST203M-C16	103.92	1	In Stock		ABB	0.79	103.92 @ 1
	us.rs-online.com	71602257	116.61	1	4		ABB		116.61 @ 1
	Galco	ST203M-C16-ABBG	122.82	1	1		ABB	0.815	122.82 @ 1
	Zoro	G3611693	125.15	1	In Stock	15	Abb		125.15 @ 1
	Newark	28AH9872	127.73	1	In Stock		ABB		127.73 @ 1
	Platt.com	1431258	136.77	1	In Stock		ABB		136.77 @ 1
