ABB Group ST203M-C20

B096MV12NM

Circuit Breaker; Miniature; DIN Rail Mount; C Curve; 3 Pole; 20A

Circuit Breaker; Miniature; DIN Rail Mount; C Curve; 3 Pole; 20Azoom

Attributes

Key Value
AC Voltage Rating277/480V AC
Alarm SwitchOptional
Amps20 A, 20
ApplicationCommercial, Industrial,.
ApprovalsUL 1077 ; CSA 22.2 No. .
Auxiliary SwitchOptional
BusbarOptional
CharacteristicC Curve
Circuit Breaker ActuatorToggle
Circuit Breaker Mountin.DIN Rail
Country of Origin (subj.Hungary
CSA Standard22.2
Current Rating20 A
Curve TypeC
DC Voltage Rating110V DC
Depth76.0 mm
Family SeriesABB Circuit Breakers, S.
Gross Weight0.805 lbs
IEC Standard60947-2
Interrupt Rating AC10 kA
ItemIEC Supplementary Prote.
Item NumberST203M-C20
kAIC @ 125 VDC10
kAIC @ 240 VAC10
kAIC @ 277 VAC5
kAIC @ 480 VAC10
kAIC @ 60 VDC10
Length86.0 mm
Length (Straight Wirewa.86.0 mm
ManufacturerABB
Manufacturer Part NumberST203M-C20
Max Voltage125 VDC, 277/480 VAC
Max. AIR Rating10kA at 277/480V AC
Max. Wire Size8 AWG
Meets UL TypeUL 1077
Min. Wire Size14 AWG
MountingDIN Rail
Mounting TypeDIN Rail Mount
Net Weight0.76 lbs
Neutral PoleNo
Number of Poles3
Phase3
Poles3
Product SeriesST200M
ProtectionSupplemental
RoHSYes
SeriesEP100, ST200 M Series
Shunt TripOptional
StandardsUL1077/CSA 22.2 No. 235.
Terminal ConnectionScrew Clamp
Terminal TypeScrew
Terminals IncludedLine and Load
TerminationScrew
Trip CurveC
Trip TypeThermal Magnetic
Trip UnitFixed Thermal / Fixed M.
TypeThermal/Magnetic, Trip .
UL Standard1077
Undervoltage ReleaseOptional
UPC Code4016779023986
Voltage Rating480 ; 480 ; 277 V
Volts AC277, 480Y
Width54.0 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomstandardelectricsupply.com235775377.661In StockABB77.66 @ 1
thumbzoomWalker IndustrialST203M-C2096.51In Stock17ABB96.5 @ 1
Airline HydraulicsABB ST203M-C20100.321In StockABB100.32 @ 1
thumbzoomalldataresource.comST203M-C20105.661In StockABB105.66 @ 1
thumbzoomZoroG3740956109.461In Stock17Abb109.46 @ 1
thumbzoomGalcoST203M-C20-ABBG122.821In StockABB0.805122.82 @ 1
us.rs-online.com71602261125.5416ABB125.54 @ 1
thumbzoomNewark28AH9876133.081In StockABB133.08 @ 1
thumbzoomPlatt.com1431262143.781In StockABB143.78 @ 1
