Acme Electric DTHA02204S

mpnDTHA02204S
brandname: Acme Electric
manufacturername: Acme Electric

Acme Electric DTHA02204S Drive Isolation Transformer, 3 Phase, 60 Hz, 220 kVA, 575 Delta Primary Volts, 230Y/133 Secondary Volts, Steel

Acme Electric DTHA02204S Drive Isolation Transformer, 3 Phase, 60 Hz, 220 kVA, 575 Delta Primary Volts, 230Y/133 Secondary Volts, Steel

zoom

Brand: Acme Electric
PartNumber: DTHA02204S
Model: ACMDTHA02204S
PackageQuantity: 1
Binding: Misc.
Manufacturer: Acme Electric
Label: Acme Electric

Attributes

Key	Value
Approvals:	UL;CSA
Brand:	Acme Electric
Circuit Diag. No.:	ACME_DTRAN_41
Diag. No.:	ACME_DTRAN_E
Item Category:	Transformers
Item Number:	DTHA-0220-4S
Motor HP:	200
Mounting:	Floor
Output (kVA):	220 KiloVolt-Amps
Phase:	3
Picture No.:	ACME_DTRAN_WS-A-1
Primary Volts AC:	575 Volts AC
Secondary Volts AC:	230 Volts AC
Series:	DT
Subcategory:	Drive Isolation Transfo.
Termination:	Pads
UPC:	047503695753
Winding:	Aluminum
