- mpnHE1WPR/04
- brandname: Altech Corp
- manufacturername: Altech Corp
ALTECH HE1WPR/04 HE1 Series 2 Row 4 Pole 8 mm Pitch 24-12 AWG Flat Base Panel Mount Eurostrip - 100 item(s)
- Brand: ALTech
- PartNumber: HE1WPR/04
- Model: HE1WPR/04
- PackageQuantity: 1
- Manufacturer: ALTECH
- Label: ALTECH
Attributes
| Key | Value |
|---|
| Agency Approvals | cULus ; VDE |
| Application | Wire-to-wire connection. |
| Approvals | CE, cURus, IEC |
| Barrier Type | - |
| Bottom Termination | Enclosed |
| Category | Connectors, Interconnec. |
| Color | Steel, White |
| Current Rating | 20 A |
| Current Rating (Amps) | 300V |
| Dimensions | 94 L x 16.2 W x 12.2 D . |
| Family Series | Altech Terminal Blocks |
| Features | White |
| Gross Weight | 0.01 lbs |
| IEC Current | 6 A |
| IEC Voltage | 400 VAC |
| IEC Wire Range (mm2) | 1-2.5 mm2 |
| Item Number | HE1WPR/04 |
| Manufacturer | Altech |
| Manufacturer Part Number | HE1WPR/04 |
| Material - Insulation | UL94 V-0 |
| Material Flammability R. | 4 |
| Mfr | Altech Corporation |
| Mounting Hole Diameter | 3 mm, 0.11 " |
| Mounting Type | Panel Mount, -30?C ~ 12. |
| Net Weight | 0.01 lbs |
| Number of Circuits | 8 |
| Number of Poles | 4 |
| Number of Rows | 20A, Double Row |
| Operating Temperature | Polyamide (PA66), Nylon. |
| Package | Active |
| Part Status | Eurostyle Terminal Strip |
| Pitch | 2 |
| Series | Bulk, HE1 Series |
| Spacing Ctr. - Ctr. | 8 mm |
| Special Features | High Voltage |
| Stripping Length | 5 mm |
| Terminal Block Type | 0.315"" (8.00mm) |
| Terminal Screw Finish | Chassis, Panel |
| Terminal Screw Material | Blue Chromate |
| Top Termination | Closed |
| Torque | 4.4 lb/in |
| Type | Euro |
| UL Current | 20 A |
| UL Voltage | 300 VAC |
| Voltage Rating | 300 V, 12-24 AWG |
| Wire Gauge | Screws |
| Wire Range (AWG) | 24-12 AWG |
| Wire Size | 12-24 AWG |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Galco | HE1WPR/04-ALTH | 0.92 | 1 | 43 | | Altech | 0.01 | 0.92 @ 1 |
| Arrow | HE1WPR/04 | 0.953 | 1 | 2428 | | Altech | | 0.953 @ 1 |
| Hawk Electronics | HE1WPR/04 | 1.01 | 50 | 99 | | Altech | | 1.01 @ 50 |
 | jensentools.com | 10121972 | 1.28 | 1 | 99 | | Altech | | 1.28 @ 1 |
| Newark | 96AK4925 | 1.52 | 100 | 65 | | ALTECH | | 1.52 @ 100 |
 | Digi-Key | 1920-1400-ND | 1.79 | 1 | 99 | | Altech Corporation | | 1.79 @ 1 |
| Mouser | 845-HE1WPR/04 | 1.82 | 1 | 233 | | Altech | | 1.82 @ 1 |
| us.rs-online.com | 70077179 | 2.05 | 1 | 224 | | Altech Corp | | 2.05 @ 1 |
