AMI Bearing UETBL206W

B01CPRVIYW

AMI: UETBL206W, 30MM WIDE ACCU-LOC WHITE TAPPED BASE PILLOW BLOCK, FACTORY NEW!

AMI: UETBL206W, 30MM WIDE ACCU-LOC WHITE TAPPED BASE PILLOW BLOCK, FACTORY NEW!zoom

Attributes

Key Value
Actual Bolt Center to C.0 Inch | 0Millimeter
base to bore centerline:1.6890 in
Base to Center Height1.689 Inch | 42.9 Milli.
base width:42.5 mm
bolt center-to-center l.76.2 mm
bolt size:7/16-14
Bolt Spacing Maximum3 Inch | 76.2Millimeter
Bolt Spacing Minimum3 Inch | 76.2Millimeter
bore diameter:30 mm
bore type:Round
BrandAMI BEARINGS
CategoryPillow Block Bearings
duty type:Normal Duty
Expansion / Non-expansi.Non-expansion
Global Part Number GPN523593
Harmonized Tariff Code8483.20.40.40
Housing Configuration1 Piece Solid
Housing MaterialThermoplastic
housing material:PBT Thermoplastic
Housing Style2 Bolt Tap Base Pillow .
Inch - MetricMetric
Insert Part NumberUE206
Length Thru Bore1.567 Inch | 39.8 Milli.
locking device:Accu-Loc
lubrication type:Lubrication Fitting
Manufacturer NameASAHI BEARINGS
Mounting Bolts7 Millimeter
Mounting MethodConcentric Collar
mounting:Tapped Base
Nominal Bolt Center to .3 Inch | 76 Millimeter
Number of Mounting Holes2
Other FeaturesSingle Row | Spherical .
overall height:84 mm
overall length:101.6 mm
overall width:45.2 mm
price$ 134.40 / each
radial dynamic load cap.2000 kgf
radial static load capa.1150 kgf
RelubricatableYes
replacement bearing:UE206
seal type:Contact with Slinger
SealsContact Seal
series:UETBL200W
titleUETBL206W
UNSPSC31171511
Weight / kgm0.65
Weight / LBS1.43

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomMRO Supply996697.581In StockAMI Bearings97.58 @ 1
thumbzoomLily BearingUETBL206W114.241In StockAMI BEARINGS1.43114.24 @ 1
thumbzoommotionindustries.com03769172153.51In StockAMI Bearings153.5 @ 1
