AMI Bearing UETBL208W

B01CPRURL2

AMI: UETBL208W, 40MM WIDE ACCU-LOC WHITE TAPPED BASE PILLOW BLOCK, FACTORY NEW!

AMI: UETBL208W, 40MM WIDE ACCU-LOC WHITE TAPPED BASE PILLOW BLOCK, FACTORY NEW!zoom

Attributes

Key Value
Actual Bolt Center to C.0 Inch | 0Millimeter
base to bore centerline:1.9370 in
Base to Center Height1.937 Inch | 49.2 Milli.
base width:47.6 mm
bolt center-to-center l.88.9 mm
bolt size:1/2-13
Bolt Spacing Maximum3.5 Inch | 88.9Millimet.
Bolt Spacing Minimum3.5 Inch | 88.9Millimet.
bore diameter:40 mm
bore type:Round
BrandAMI BEARINGS
CategoryPillow Block Bearings
duty type:Normal Duty
Expansion / Non-expansi.Non-expansion
Global Part Number GPN523581
Harmonized Tariff Code8483.20.40.40
Housing Configuration1 Piece Solid
Housing MaterialThermoplastic
housing material:PBT Thermoplastic
Housing Style2 Bolt Tap Base Pillow .
Inch - MetricMetric
Insert Part NumberUE208
Length Thru Bore1.969 Inch | 50 Millime.
locking device:Accu-Loc
lubrication type:Lubrication Fitting
Manufacturer NameASAHI BEARINGS
Mounting Bolts1 Inch
Mounting MethodConcentric Collar
mounting:Tapped Base
Nominal Bolt Center to .3.5 Inch | 90 Millimeter
Number of Mounting Holes2
Other FeaturesSingle Row | Spherical .
overall height:100.4 mm
overall length:120 mm
overall width:55 mm
price$ 184.28 / each
radial dynamic load cap.2990 kgf
radial static load capa.1830 kgf
RelubricatableYes
replacement bearing:UE208
seal type:Contact with Slinger
SealsContact Seal
series:UETBL200W
titleUETBL208W
UNSPSC31171511
Weight / kgm1.1
Weight / LBS2.43

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomMRO Supply6284133.781In StockAMI Bearings133.78 @ 1
thumbzoomLily BearingUETBL208W156.641In StockAMI BEARINGS2.42156.64 @ 1
thumbzoommotionindustries.com03769176210.441In StockAMI Bearings210.44 @ 1
