- mpnAD8592ARMZ-REEL
- brandname: Analog Devices Inc.
- manufacturername: Analog Devices Inc.
AD8592ARMZ-REEL
- Brand: ANALOG DEVICES
- PartNumber: AD8592ARMZ-REEL
- Model: AD8592ARMZ-REEL
- PackageQuantity: 1
- Manufacturer: Analog Devices Inc
- Label: Analog Devices Inc
Attributes
| Key | Value |
|---|
| Alternate Part No. | 584-AD8592ARMZ-R |
| Alternate Parts | AD8592ARM |
| Amplifier Type | General Purpose |
| Base Part Number | AD8592 |
| Base Product Number | AD8592 |
| Brand | Analog Devices |
| Category | Integrated Circuits (IC. |
| CMRR - Common Mode Reje. | 45 dB |
| Current - Input Bias | 5 pA, 5pA |
| Current - Output / Chan. | 250 mA, 250mA |
| Current - Supply | -, 1.25mA |
| Description | IC OPAMP GP 2 CIRCUIT 1. |
| Detailed Description | General Purpose Amplifi. |
| Digi-Key Part Number | AD8592ARMZ-REELTR-ND - . |
| en - Input Voltage Nois. | 45 nV/rtHz at 5 V |
| Gain Bandwidth Product | 3 MHz, 3MHz |
| GBP - Gain Bandwidth Pr. | 3 MHz |
| Ib - Input Bias Current | 60 pA |
| Lead Free Status / RoHS. | RoHS Compliant |
| Manufacturer | Analog Devices Inc. |
| Manufacturer Part No. | AD8592ARMZ-REEL |
| Manufacturer Part Number | AD8592ARMZ-REEL |
| Manufacturer Product Nu. | AD8592ARMZ-REEL |
| Manufacturer Standard L. | 7 Weeks, 26 Weeks |
| Maximum Operating Tempe. | + 85 C |
| Mfr | Analog Devices Inc. |
| Minimum Operating Tempe. | - 40 C |
| Mounting Style | SMD/SMT |
| Mounting Type | Surface Mount |
| Number of Channels | 2 Channel |
| Number of Circuits | 2 |
| Operating Temperature | -40?C ~ 85?C, -40 |
| Output Type | Rail to Rail Input/Outp. |
| Package | Tape & Reel (TR) |
| Package / Case | 10-TFSOP, 10-MSOP (0.11. |
| Package/Case | MSOP-10 |
| Packaging | Reel |
| Part Status | Active |
| Product | Operational Amplifiers |
| Product Category | Precision Amplifiers |
| Product Status | Active |
| PSRR - Power Supply Rej. | 55 dB |
| Series | AD8592, - |
| Shutdown | Yes |
| Slew Rate | 5V/, 5V/?s |
| SR - Slew Rate | 5 V/us at 5 V |
| Standard Package | 3,000 |
| Supplier Device Package | 10-MSOP |
| Supply Current per Chan. | 2.5 mA |
| Supply Type | Single |
| Supply Voltage - Max | 6 V |
| Supply Voltage - Min | 2.5 V |
| Voltage - Input Offset | 2mV, 2 mV |
| Voltage - Span (Max) | 6 V |
| Voltage - Span (Min) | 2.5 V |
| Voltage - Supply Span (. | 6 V |
| Voltage - Supply Span (. | 2.5 V |
| Voltage - Supply, Singl. | 2.5V ~ 6V, |
| Voltage Gain dB | 89.54 dB |
| Vos - Input Offset Volt. | 25 mV |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Hotenda | H2509086 | 0.4641 | 1 | 215 | | Analog Devices, Inc. | | 0.4641 @ 1 |
| iodParts | AD8592ARMZ-REEL | 0.611 | 500 | 3000 | | Analog Devices | | 0.611 @ 500 |
| RS Delivers | 160-4528 | 0.768 | 1 | 156 | | Analog Devices | | 0.768 @ 1 |
 | swatee.com | AD8592ARMZ-REEL | 1.68 | 1 | 1563 | | Analog Devices Inc. | | 1.68 @ 1 |
 | Digi-Key | 652867 | 1.69 | 1 | 47853 | | Analog Devices Inc. | | 1.69 @ 1 |
 | Newark | 60AK7609 | 1.7 | 1 | 3710 | | ANALOG DEVICES | | 1.7 @ 1 |
