APOLLO 77C20801A

mpn77C20801A
brandname: Apollo
manufacturername: Apollo

Apollo 77C20801A Bronze Ball Valve (Pack of 4)

Brand: APOLLO
PartNumber: 77C20801A
Model: 77C20801A
PackageQuantity: 1
Binding: Misc.
Manufacturer: Apollo
Label: Apollo

Attributes

Key	Value
Actuator Type	Lever Operated
ANSI	ANSI Z1157
ASTM	ASTM B-16, ASTM B-283, .
BAA Compliant	Yes
Ball Material	Chrome Plated Brass
Ball Valve Basic Body M.	Bronze
Ball Valve Product Group	Manual
Body Material	Bronze
Body Seal Material	RPTFE
Body Style	Inline
Brand	Apollo Valves
Clean Bagged	No
Collection	77C-A Series
Color Finish Name	Bronze
Compliance	MSS SP-110
Connection Type	Sweat x Sweat
cUPC Certified	Yes
Current Stock	9
Description:	BV,2"SLDR,BRZ,FP
Domestic/Import	Domestic
End Connection 1	Sweat
End Connection 2	Sweat
End Connections	Sweat
End Style	Solder
Features	Dezincification Resista.
Fire Suppression System.	No
FM Approved	No
Handle Length (in)	7-18/25 in
Handle Material	Zinc Plated Steel, Zinc.
Handle Type	Lever
Height	3-17/25 in
Hose I.D.	2 in
IAPMO Listed -	Yes
Inlet to Outlet Length	6.07 in
International Shipping	No
ISO	ISO 9001
Item	Ball Valve
Lead Law Compliance Lev.	Not Compliant, Approved.
Lead Time	Expected to ship in 1-2.
Length	3-83/100 in
Manufacturer	Apollo Conbraco Industr.
Material	Cast Bronze
Material Type	B584, C84400
Max. Pressure	600 psi CWP
Max. Steam Pressure	150 psi WSP
Maximum Temperature	450
Media	Water
MFG Part #:	77C20801A
Minimum Temperature	-20
Mpn	77C20801A
MSS	MSS SP-110
Nominal Size	2 in
NSF Certified	No
Number of Pieces	1 Piece
Origin	Domestic
Pipe Size	2"
Port	Full
Port Type	Full
Pressure - Maximum	600 psi
Pressure Class	600#
Pressure Rating	600 psi CWP
Prop 65	WARNING: Cancer and Rep.
Recommended Valve Appli.	Potable Water, Steam
Seat Material	RPTFE
Series	77C-A
SKU	ZO-G3956736
Softgoods Material	RPTFE
Standard Pack:	Order QTY must be in mu.
Standards	IAPMO RT/UPC-Z1157
Stem Material	brass
Stem Type	Blowout Proof
SubCategory	Plumbing
Supplier:	Apollo Conbraco Industr.
Temp. Range	-20 Degrees to 450 Deg.
Temperature Range	-20 to 450 Deg F
Temperature Rating	450 deg F, 450
Top to Inlet Center	3.83 in
Trim Material	Brass Stem and RPTFE Se.
Tube Size	2"
Type	2-Piece
UL Listed	No
UPC	670750351570
UPC:	670750351570
Valve Body Material	Bronze
Valve Disc Material	brass
Valve Operator	Lever Handle
Valve Port Opening	Full Port
Valve Seat Material	RPTFE
Valve Size	2 in
Valve Stem	Blowout-proof
Valve Structure	2-Piece
Valve Type	Ball Valve
Weight	7.9 lb

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
Zoro	G3956736	130.99	1	33		Apollo Valves	7.25	130.99 @ 4
simsupply.com	ZO-G3956736	155.12	1	9		Apollo Valves		155.12 @ 4
supply.com	77C20801A	166.8	1	158		Apollo		166.8 @ 4
kscdirect.com	APO 77C20801A	190.18	1	4		Apollo Conbraco Industries		190.18 @ 4
sustainablesupply.com	C2862128	220.96	1	4		Apollo Valves	7.25	220.96 @ 4
AF Supply	77C20801	222.38	1	4		Apollo		222.38 @ 4
ferguson.com	7099882	223.17	1	4		Apollo Valves	7.9	223.17 @ 4
bpssg.com	102556	235.9	1	4		Apollo		235.9 @ 4
AmazonTP	B01EBUQU3K	801.32	1	4	5	Apollo		801.32 @ 4
