mpn:
brand:
manufacturer:
MPN:
Weight:
30.35
Weight:
30.35 LB
Preferred Price:
7125.94
Price:
7125.94
Min Simple Price:
4025.96
Absolute Min Price:
5716.86
Min Price:
5716.86
Dimensions:
[21.0, 19.0, 16.0]
qty:
21
simpleSku:
NDAxMw:::DBR1034EH90
sku:
NDAxMw::JI:DBR1034EH90@y0
condition:
11
seller:
gordonelectricsupply.com
amzMan:
appleton
HazMat:
False
DropShip:
True
Attributes
| Key | Value |
|---|---|
| Amperage Rating | 100 A |
| Amps | 100 A |
| Approvals | UL |
| Aux/Pilot Contacts | None |
| Built-In Strain Relief | Yes |
| Case Material | Metallic |
| Category | Electrical Receptacles |
| Circuit Breaker | Yes |
| Circuit Breaker Amp Rating | 90 A |
| Circuit Breaker Type | EHD 480V AC |
| Comments | Explosionproof, Dust-Ignitionproof, 3 poles and 1 ground wire |
| Compatible Plug Manufacturer Part Number | Not Applicable |
| Compatible with Series | Powertite |
| Connection Description | Non-Fusible |
| Connection Type | Receptacle |
| Contact Material | Brass |
| Country of Origin | MX |
| Country of Origin (subject to change) | Mexico |
| Current Rating | 100 A |
| Description: | DBR 100A 3W 4P WEST EHB 90A |
| Dimensions | 16.57 in H x 5.57 in W x 14.14 in D |
| Disconnect Switch | No |
| Enclosure Lock Type | Padlockable |
| Family Series | Appleton Plugs & Receptacles, DBR Series |
| Finish | Epoxy Powder Coated |
| For Environment | Hazardous Location |
| For Maximum Cable Diameter | Not Applicable |
| For Minimum Cable Diameter | Not Applicable |
| Fuse Protection | Not Applicable |
| Fuse Type | Not Applicable |
| Gross Weight | 0 lbs |
| Grounding | Grounded |
| Handle Type | Knob |
| Hazardous Location Specification | Class I, Div 1 and 2, Group B, C, D, Class II, Div 1 and 2, Group F, G, Class III, Div 1 and 2 |
| Horsepower Rating | 40 hp |
| Housing Material | Copper-Free Aluminum |
| Housing Material Finish | Epoxy Powder Coated |
| Housing Material Type | Metallic |
| HP | 40 hp |
| Hub Diameter | 1.5 in |
| Hub Type | Feed Through |
| Includes | Screw Cap |
| Includes Mounting Hardware | Yes |
| Insulation Material | Fiberglass-Reinforced Polyester |
| Item | Receptacle |
| Item Number | DBR1034EH90 |
| Locking Handle | Yes |
| Lockout-Tagout | No |
| Manufacturer | Appleton-Emerson Industrial Automation, Appleton Electric Co, Appleton |
| Manufacturer Part Number | DBR1034EH90 |
| Material | Copper-Free Aluminum, Copper Free Aluminum |
| Maximum Wire Size | Not Applicable |
| MFG Part #: | DBR1034EH90 |
| Mounting Box | Copperfree Aluminum |
| NEMA Enclosure Rating | 3, 3R, 4, 4X, 9FG |
| NEMA Rating | NEMA 3/3R/4/4X/9FG, 3, 3R, 4, 4X, 9FG |
| Net Weight | 0 lbs |
| Number of Gangs | 1 |
| Number of Poles | 4 |
| Number of Poles & Wires | 4 Pole / 3 Wire |
| Number of Wires | 3 |
| Phase | Three |
| Product Series | DBR |
| Product Type | Receptacle |
| Resistance Properties | Waterproof |
| Series | DBR |
| Standards | E10784, UL 1010 (UL 1203), UL 1682, UL 894 |
| Supplier: | Appleton-Emerson Industrial Automation |
| Type | Dust-Ignitionproof |
| UNSPSC | 39121406 |
| UPC | 781381474849 |
| UPC: | 78138147484 |
| Voltage | 600V AC, 600 V |
| Voltage Rating | 480V AC, 600 VAC |
| Wire Connection Type | Quick-Disconnect Terminals |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | gordonelectricsupply.com | DBR1034EH90 | 4025.96 | 4025.96 | 1 | In Stock | 380 | APPLETON | 4025.96 @ Qty: 1+ | |
 | Zoro | G3046806 | 4283.0 | 4283.0 | 1 | In Stock | 26 | Appleton Electric | 45.0 | 4283.0 @ Qty: 1+ |
| Dale-Electric | DBR1034EH90 | 5128.13 | 5128.13 | 1 | In Stock | Appleton Electric Co | 5128.13 @ Qty: 1+ | |||
 | Galco | DBR1034EH90-APTN | 5389.77 | 5389.77 | 1 | In Stock | Appleton | 5389.77 @ Qty: 1+ | ||
| kscdirect.com | APP DBR1034EH90 | 5658.69 | 5658.69 | 1 | In Stock | Appleton-Emerson Industrial Automation | 5658.69 @ Qty: 1+ | |||
| Platt.com | 0374974 | 7359.43 | 7359.43 | 1 | In Stock | Appleton | 7359.43 @ Qty: 1+ | |||
 | sustainablesupply.com | C1159438 | 8918.46 | 8918.46 | 1 | In Stock | Appleton Electric | 45.0 | 8918.46 @ Qty: 1+ | |
 | Raptor Supplies | AA4DPN | 12019.378644 | 12019.378644 | 1 | In Stock | APPLETON ELECTRIC | 12019.378644 @ Qty: 1+ |
