- mpn83001 0021000
- brandname: Belden
- manufacturername: Belden
Belden 83001 0021000, WIRE, HOOK UP, HIGH TEMPERATURE, 28AWG, STRANDED, TFE TEFLON, 600V, UL 1213 RED
- Brand: Belden
- PartNumber: 83001 0021000
- Model: 83001 0021000
- Color: Red
- PackageQuantity: 1
- Manufacturer: Belden
- Label: Belden
Attributes
| Key | Value |
|---|
| Base Product Number | 83001 |
| Cable external diameter | 0.89mm |
| Cable Type | Hook-Up |
| Category | Cables, Wires |
| Conductor Material | Copper, Silver Coated, . |
| Conductor Strand | 7/36 |
| Conform to the norm | MIL-W-16878/4 |
| Core diameter | 28AWG |
| Core structure | stranded |
| CPR standard | no classification |
| Description | HOOK-UP STRND 28AWG RED. |
| Detailed Description | 28 AWG Hook-Up Wire 7/3. |
| Digi-Key Part Number | BEL4896-1000-ND |
| Features | High Temperature |
| Insulated / Uninsulated | Insulated |
| Insulation Color | red |
| Insulation colour | red |
| Insulation Material | Tetrafluoroethylene (TF. |
| Insulation Thickness | 0.01 in. |
| Jacket (Insulation) Dia. | 0.035" (0.89mm) |
| Jacket (Insulation) Mat. | Polytetrafluoroethylene. |
| Jacket (Insulation) Thi. | 0.010" (0.25mm) |
| Jacket Color | red |
| Kind of core | Cu, |
| Length | 1000.0' (304.8m), 1000 . |
| Manufacturer | BELDEN, Belden Inc. |
| Manufacturer Product Nu. | 83001 0021000 |
| Manufacturer Standard L. | 12 Weeks |
| Max. Voltage | 600V |
| Maximum Operating Tempe. | 105C (UL AWM), 200C (MI. |
| Mfr | Belden Inc. |
| Number of Conductors | 1 |
| Number of cores | 1 |
| Operating Force | Tetrafluoroethylene (TF. |
| Operating Temperature | - |
| Operating temperature | -70...200?C |
| Outer Diameter | 0.035 (0.89) in. (mm) |
| Package | Spool |
| Package contents | 305m |
| Packaging | Coil |
| Product Status | Active |
| Ratings | UL Style 1213 |
| Series | MIL-W-16878/4, 83001 Se. |
| Shield | red |
| Shielded / Unshielded | Unshielded |
| Standards | UL AWM 1213; VW-1, UL L. |
| Stranding | 7 x 36, 7x36 |
| Temp. Rating | 200?C |
| Temperature, Rating | 105 C |
| Type of wire | assembly |
| Voltage | 600V |
| Voltage Rating | 600 V |
| Wire Gauge | 28 AWG |
| Wire insulation material | PTFE |
| Wire Material | Silvered Copper |
| Wire Size | 28 AWG |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| TME | 83001.0021000 | 1.06 | 305 | 94 | | BELDEN | | 1.06 @ 305 |
 | alldataresource.com | B83001-2 | 1.39 | 1 | 94 | | Belden | | 1.39 @ 1 |
| AmazonSC | B015GQEB70 | 387.85 | 1 | 94 | | Belden | | 387.85 @ 1 |
 | Zoro | G2684858 | 432.0 | 25 | 94 | 30 | Belden | | 432.0 @ 25 |
 | Digi-Key | 8123403 | 707.16 | 1 | 94 | | Belden Inc. | | 707.16 @ 1 |
| us.rs-online.com | 70003460 | 799.3 | 1 | 5 | | Belden | | 799.3 @ 1 |
 | Newark | 87K1588 | 885.82 | 1 | 29 | | BELDEN | | 885.82 @ 1 |
