Belden 9116SB 0101000

B005T6IBME

Coaxial Cable, CATV, Black, 18 AWG, Solid, 1000 ft, 304.8 m

Coaxial Cable, CATV, Black, 18 AWG, Solid, 1000 ft, 304.8 mzoom

Attributes

Key Value
ApplicationFor CATV
AWG Size18
Cable TypeCoaxial
CategoryCables, Wires
ColorBlack
Conductor Count1
Conductor MaterialBare Copper Covered Ste.
CPR EuroclassEca
Environmental SpaceIndoor/Outdoor
EU CE MarkYes
EU Directive 2015/863/EUYes
IEEE Flammability1202
IEEE SpecificationStd. 45 clause 23
Impedance75 Ohms
Insulation MaterialFoam Polyethylene (FPE).
ISO/IEC FlammabilityIEC 60332-1-2;IEC 60332.
Jacket ColorBlack
Jacket MaterialLow Smoke Zero Halogen .
Length1000 ft
Material@Insulation01PE - Polyethylene (Foam)
Material@OuterShield1 2Aluminum
MfrBelden Inc.
Number of Conductors1
Operating ForceFoam Polyethylene (FPE)
Other SpecificationABS Type Approval Certi.
Outer Diameter0.274 "
PackageSpool
PackagingCoil
Part StatusActive
Product HeaderBroadband Coaxial CATV .
Series*, Shipboard Series
Shield MaterialAluminum
ShieldingFoil & Braid, Yes
StandardsUL NEC Type CMG-LS/cUL .
StrandingSolid
Stranding@Conductor1Solid
Suitability - IndoorYes
Suitability - OutdoorYes
Temperature, Rating-30 to +90 C (Dry), -30.
UL FlammabilityUL1685 FT4 Loading, Lim.
UL voltage rating300 V RMS
Wire Size18 AWG

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Digi-Key8810021592.491In StockBelden Inc.592.49 @ 1
us.rs-online.com70004639667.9712Belden667.97 @ 1
thumbzoomNewark66K6059707.531In StockBELDEN707.53 @ 1
thumbzoomZoroG317734413149.7525In StockBelden Bav13149.75 @ 25
