Black Box C6PC28-RD-02

mpnC6PC28-RD-02
brandname: BLACK BOX
manufacturername: BLACK BOX

Black Box C6PC28-RD-02 CAT6 250-MHZ Stranded ETHERNET Patch Cable - UNSHIELDED (UTP), cm PVC, SNAGLESS

Brand: Black Box
PartNumber: C6PC28-RD-02
Model: C6PC28-RD-02
Color: black
Size: 2 Feet
PackageQuantity: 1
Binding: Personal Computers
Manufacturer: BLACKBOX NETWORK SERVICE
Label: BLACKBOX NETWORK SERVICE

Attributes

Key	Value
ACR	100 MHz: 24.4 dB/100 m;.
ACRF	100 MHz: 27.8 dB/100 m;.
American Wire Gauge	28 AWG
Approvals	UL?E196163
Best Sellers Rank	#3,117 in Cat 6 Etherne.
Brand	Black Box Network Servi.
Brand Name	Black Box
Cable Characteristic	Patch Cable
Cable Length	2 ft
Cable Type	Ethernet, Category 6
Color	Red
Conductor Gauge	28 AWG, stranded bare c.
Connector on First End	1 x RJ-45 Male Network
Connector on Second End	1 x RJ-45 Male Network
Connector Type	RJ45
Contact Plating	Gold
Country of Origin	China
cpuCode	ETHERN
Data Transfer Rate	10 Gbit/s
Date First Available	August 9, 2018
Delay Skew	1-10 MHz: 40 +/- 10 nS/.
Device Supported	Patch Panel, Wallplate,.
Environmental Certifica.	RoHS
Environmentally Friendly	Yes
Features	Stranded, Snagless, Boo.
Frequency	250 MHz
Gauge	28.0
Height	0.50
Impedance	100 ? 15 ohms
ingramMicroCategory	2240
Insertion Loss (Maximum)	100 MHz: 19.8 dB/100 m;.
Insulation	HDPE
Is Discontinued By Manu.	No
Item model number	C6PC28-RD-02
Jacket	PVC, CM
Jacket Type	CM
Length	3.00
Limited Warranty	Lifetime
Manufacturer	Black Box Network Servi.
Manufacturer Part Number	C6PC28-RD-02
Manufacturer Website Ad.	http://www.blackbox.com
Material	Polyvinyl Chloride (PVC.
mediaType	CABL
NEXT	100 MHz: 44.3 dB/100 m;.
Outer Diameter	0.161"" (4.1 mm)
Package Quantity	1
Pair-to-Ground Capacita.	330 pF/100 m max.
Product Dimensions	3 x 3 x 0.5 inches
Product Line	Slim-Net
Product Name	Slim-Net Cat.6 UTP Patc.
Product Type	Network Cable
Product with faster shi.	true
Product with good Gross.	true
Propagation Delay	250 MHz: 535.5 ns/100 m.
PS-ACR	100 MHz: 22.4 dB/100 m;.
PS-ACRF	100 MHz: 24.8 dB/100 m;.
PS-NEXT	100 MHz: 42.3 dB/100 m;.
Resistance	22.3 ohms/100 m
Return Loss	100 MHz: 19.0 dB/100 m;.
Shielding	No
Shipping	undefined (Fixed Shippi.
Weight	0.05
Width	3.00

All Prices

Seller	Supplier SKU	Min Price	MOQ	In Stock	Brand	Weight	Preferred Tier
CDW	4997750	4.59	1	2	Black Box		4.59 @ 2
directdeals.com	C6PC28-RD-02	4.59	1	2	Black Box		4.59 @ 2
Newark	83Y9078	5.97	1	2	BLACK BOX		5.97 @ 2
ipcstore.com	14_C6PC28-RD-02_1	6.0	1	2	Black Box		6.0 @ 2
Megadepot	C6PC28-RD-02	6.54	1	2	BlackBox		6.54 @ 2
usmegastore.com	C6PC28-RD-02	6.68	1	2	BlackBox		6.68 @ 2
unbeatablesale.com	SYBA165433	7.89	1	2	BLACK BOX		7.89 @ 2
PCNation	2PG677	9.92	1	2	BLACK BOX CORPORATION	1.0	9.92 @ 2
Zoro	G9516878	10.1	2	2	Black Box		10.1 @ 2
barcodegiant.com	BLA629058	13.18	1	2	Black Box		13.18 @ 2
homeessentialsdirect.com	C6PC28-RD-02	19.86	1	2	Black Box Network Services		19.86 @ 2
