Edison Fuse ECNR20

B00QW2QHQG

Edison Fuse ECNR20 Edison 20 amp fuse dual-element time delay 250V replaces FRN-R-20

Edison Fuse ECNR20 Edison 20 amp fuse dual-element time delay 250V replaces FRN-R-20zoom

Attributes

Key Value
AC Voltage Rating250V AC
Additional InformationNumber of Elements 2; R.
Alarm ContactNo
Amperage Rating:20 A
Amps20A
ApplicationAC Power Distribution S.
ApplicationsElectrical, Industrial
ApprovalCE, UL, Class RK5, JDDZ.
Approval AgencyCE, CSA, UL
ApprovalsCE, CSA, UL
Body MaterialFiberglass
Body StyleCylindrical
BrandEdison Fuses, Bussmann
Breaking Capacity @ Rat.200kA
Carton1
CategoryCircuit Protection, Car.
Category DescriptionFuses & Fuse Accessories
CharacteristicTime Delay
CharacteristicsTime Delay, Current Lim.
ClassRK5, Class RK-5
Class:RK-5
ClassificationFuses & Fuse Accessories
Commodity DescriptionDUAL ELEMENT FUSES
Compatible Fuse Block S.R250
Connection TypeFerrule end x ferrule e.
Connection:Ferrule end x ferrule e.
Country of OriginMX, Mexico
Country of Origin (subj.Mexico
Current Rating20 A
Current Rating (Amps)20A
DC Voltage Rating125V DC
DescriptionFUSE CARTRIDGE 20A 250V.
Detailed Description20A 250 VAC 125 VDC Fus.
Diameter9/16", 0.56 in
Digi-Key Part NumberECNR20-ND
Dimensions0.5625 x 2 in
Dimensions:7.1300 IN X 1.5600 IN X.
ElementDual
Element:Dual
Equivalent Brand and Se.Bussmann FRN-R, Edison .
Equivalent SeriesECNR, FLNR, FRN-R, TR-R
extra long descriptionCLASS RK5 TYPE; 2 INCH;.
Family SeriesBussmann Fuses, ECNR Se.
Features-, These fuses are reco.
Fits Fuse Block StyleRejection
Functionally Equal ToLittelfuse FLNR, Mersen.
Fuse Amps20A
Fuse ClassRK5 Class
Fuse Holder CodeH
Fuse Interrupt Rating200kA at 250VAC, 20kA a.
Fuse Size2" L x 9/16" dia
Fuse SpeedTime Delay
Fuse TypeCartridge, Ferrule
Fuse Voltage Rating250VAC/125VDC
Gross Weight0.05 lbs
GTIN00782634507321
Height0.550
Indicating / Nonindicat.Nonindicating
interrupt rating200000 A
Interrupt Rating200kA at 250V AC, 20kA .
Interrupt Rating:200 kAIC
Interrupting Rating200 Kiloamp
ItemFuse
Item NumberECNR20
Length2.050, 2 INCH, 2"
Length (Straight Wirewa.2 in
Long DescriptionTime Delay Power Fuse, .
Made in USAyes
ManufacturerEaton - Bussmann Electr.
Manufacturer Part NumberECNR20
Manufacturer Product Nu.ECNR20
Manufacturer Standard L.5 Weeks
Manufacturers Part Numb.ECNR20
Maximum Amperage20
MfrEaton - Bussmann Electr.
Mounting TypeRequires Holder
Net Weight0.05 lbs
Operating Temperature-
Overall Length2 in
PackageBulk, 10
Package / CaseCartridge, Non-Standard
Package Quantity1
package quantity10 CT
Package TypeCartridge
Primary TypeSingle Use Fuses
Product SeriesECNR
Product StatusActive
Product TypeTime Delay Power Fuse
Rejection / NonrejectionRejection
Response TimeSlow Blow, 8 s @ 500%
Response Time:10 S at 500%
RoHSNo
SeriesECNR, ECNR Series
Short DescriptionPower Fuse, 20 A, 250 V.
Size / Dimension0.560" Dia x 2.000" L (.
Size MeasureIN
Size:0.56 In Diameter X 2.00.
SpeedTime Delay
Standard:CE Marked
StandardsCE, CSA Certification C.
Standards MetUL Listed Std. 248-12,C.
Sub Brand:Edison
Terminal TypeFerrule
Trip IndicatorNo
TypeFerrule Fuses, Class RK.
Type:Fuse
UNSPSC39121604 - Time delay f.
UPC782634507321
UPC Code782634507321
Visual IndicationNonindicating
Voltage250
Voltage (AC)250 VAC
Voltage (DC)125 VDC
Voltage Rating250 V, 250 V ac;125 V dc
Voltage Rating - AC250 VAC
Voltage Rating - DC125 VDC
Voltage Rating:250/125 VAC//VDC
Weight0.50 lb;0.23 kg, 0.050
Weight MeasureLB
Weight per each0.05
Width0.500

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Dale-ElectricECNR204.0816Cooper Bussmann4.08 @ 1
thumbzoomgsistore.comECNR205.951In StockCooper Bussmann5.95 @ 1
thumbzoomZoroG40706047.051In StockEaton Bussmann0.057.05 @ 1
thumbzoomsustainablesupply.comC11610058.711In StockEaton0.058.71 @ 1
thumbzoomAI ConsolidatedECNR20-BUSSMANN8.811In StockBussmann Eaton Cooper Fuses0.058.81 @ 1
WaldomEATON ECNR209.631In StockEaton9.63 @ 1
thumbzoomHD Supply34267611.291In StockBussmann0.0511.29 @ 1
thumbzoomWalker IndustrialECNR2014.9810In Stock17Cooper Bussmann14.98 @ 10
thumbzoomElliott ElectricECNR2015.121In StockEdison0.0515.12 @ 1
thumbzoomGalcoECNR20-BUSS15.4211Bussmann0.0515.42 @ 1
thumbzoomDigi-Key543401316.4118Eaton - Bussmann Electrical Division16.41 @ 1
us.rs-online.com7142110321.04110Bussmann by Eaton21.04 @ 1
Newark75T418023.4710In StockEATON BUSSMANN23.47 @ 10
thumbzoomPlatt.com096212025.161In StockEaton/Bussmann Series25.16 @ 1
thumbzoomAutomation DirectECNR2078.0134Edison0.4978.0 @ 1
standardelectricsupply.com2315288171.11In StockBussmann171.1 @ 1
