- mpnATP16-DL5-306-B4SA-04G
- brandname: C&K COMPONENTS
- manufacturername: C&K COMPONENTS
ATP16-DL5-306-B4SA-04G, Switch Push Button N.C. SPST Dome 2A 36VDC Momentary Contact Panel Mount Solder Lug Tray (5 Items)
- Brand: CandK
- PartNumber: ATP16-DL5-306-B4SA-04G
- Model: ATP16-DL5-306-B4SA-04G
- Manufacturer: CandK
- Label: CandK
Attributes
| Key | Value |
|---|
| Actuator Marking | Power Symbol |
| Actuator Type | Round, Button, Domed |
| Base Product Number | ATP16 |
| Category | Switches |
| Circuit | SPST-NO |
| Color - Actuator/Cap | Silver |
| Current Rating (Amps) | 2A (DC) |
| Description | SWITCH ANTIVANDAL 16MM . |
| Detailed Description | Pushbutton Switch SPST-. |
| Digi-Key Part Number | CKN12298-ND |
| Electrical Life | 200,000 Cycles |
| Features | - |
| Illumination Type, Color | LED, Red |
| Illumination Voltage (N. | 6 VDC |
| Ingress Protection | IP67 - Dust Tight, Wate. |
| Manufacturer | C&K |
| Manufacturer Product Nu. | ATP16-DL5-306-B4SA-04G |
| Manufacturer Standard L. | 12 Weeks |
| Mechanical Life | 1,000,000 Cycles |
| Mfr | C&K |
| Mounting Type | Panel Mount, Front |
| Operating Temperature | -20?C ~ 70?C |
| Package | Tray |
| Panel Cutout Dimensions | Circular - 16.00mm Dia |
| Product Status | Active |
| Series | ATP16 |
| Switch Function | Off-Mom |
| Termination Style | Solder Lug |
| Type | Anti-Vandal, Illuminated |
| Voltage Rating - DC | 36 V |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Digi-Key | 10059236 | 12.912 | 1 | 546 | | C&K | | 12.912 @ 5 |
 | Newark | 34AH5808 | 13.66 | 1 | 398 | | C&K COMPONENTS | | 13.66 @ 5 |
