| Accuracy Pressure and absolute ranges | ?0.1% full scale, ?1 least significant digit |
| Accuracy Sensor hysteresis | ?0.015% FS, included in accuracy |
| Accuracy Sensor repeatability | ?0.01% FS, included in accuracy |
| Accuracy Vacuum, compound, bipolar ranges | ?0.25% full scale ?1 least significant digit |
| Auto Shutoff | User selectable 1 minute to 8 hours or front button on/off |
| Batteries, Battery Life, Low Battery Indication | 2 AA alkaline included Approx. 150-1500 hours depending on backlight usage Low battery symbol on display |
| Connection | 1/4" NPT male fitting |
| Dimensions | 3.67"W x 3.19"H x 2"D with boot, not including fitting |
| Display | 3 readings per second nominal display update rate 4 digit LCD, 0.5"H and 5 character 0.25"H alphanumeric White LED backlight active with button keypress |
| Environmental Temperature Compensated range | 32 to 158?F (0 to 70?C) |
| Environmental Temperature Operating | -4 to 185?F (-20 to 85?C) |
| Environmental Temperature Storage | -40 to 203?F (-40 to 95?C) |
| Housing Materials | Epoxy powder coated aluminum case and bezel, front and rear rubber gaskets, polycarbonate label, rubber boot |
| Material | All wetted parts are 316L stainless steel |
| Min/Max Memory | Minimum and/or maximum readings stored in memory, readings cleared or stored at shutoff. User configurable. |
| Pounds/sq. inch | 15-0 psia |
| PSI | 15.0 abs |
| Weight Gauge | 9 ounces (approximately) |
