Leeson B598

mpnB598
brandname: CENTURY
manufacturername: CENTURY

LEESON B598 Farm Duty Motor,115/208-230V AC

LEESON B598 Farm Duty Motor,115/208-230V AC

zoom

Brand: Leeson
PartNumber: B598
PackageQuantity: 1
Binding: Misc.
Manufacturer: Century Electric Motor
Label: Century Electric Motor

Attributes

Key	Value
Bolt Circle Dia.	5 7/8 in
Category	Electric Motor
Country of Origin (subj.	Mexico
Duty	Continuous
Duty Cycle	Continuous
Enclosure	TENV
Finish	Black
Frame	56HCZ
Frame Material	Rolled steel
Frame Remarks	FOOTED
Full Load Amps	2.5-2.4
HP	3/4, 0.75
Hz	60
Includes	Stainless Steel Shaft
Ins. Class	B
Item	Milk Pump Motor
Item - Farm Duty Motors	Milk Pump Motor
Item Condition	FACTORY NEW
Length Less Shaft	10 5/16 in
Manufacturer	Century
Max. Ambient Temp.	40 Degrees C
Max. Ambient Temperature	40 Degrees C
Motor Application	Farm Duty
Motor Bearings	Ball
Motor Design	3-Phase
Motor Efficiency Group	Standard Efficient
Motor Enclosure Design	Totally Enclosed Nonven.
Motor Frame Material	Steel
Motor Mounting Position	Horizontal, Vertical Sh.
Motor Mounting Type	Rigid Base
Motor Service Factor	1
Motor Shaft Design	Keyed
Motor Shaft Rotation	CW/CCW
Motor Sub Application	Milk Pump
Motor Thermal Protection	Auto
mounting	C-face w/ rigid base
Nameplate RPM	3,450
No. of Speeds	1
Nominal Efficiency	67 %
Overall Length	12 3/16 in
Phase	3, Three
RPM	3450, 3600
RPM Range	3,001-3,600
Shaft Dia.	5/8 in
Shaft Length	1 7/8 in
Standards	CSA Certified, UL Recog.
Usable @ 200V	No
Usable @ 208V	Yes
Voltage	208-230, 208-230V AC
Voltage Compatibility	208V AC, 208-220/440V A.
Volts	208/230
Weight	26 lb

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Zoro	G5640442	333.89	1	In Stock	15	Century	26.0	333.89 @ 1
	sustainablesupply.com	C1529030	460.79	1	In Stock		Century	28.6	460.79 @ 1
	MRO Supply	5812213	483.04	1	In Stock		Century		483.04 @ 1
	midwestapplianceparts.com	B598-AO-P	489.19	1	In Stock		AO Smith		489.19 @ 1
	Dealers Electric	B598	515.24	1	In Stock		Century	38.0	515.24 @ 1
