- mpnEP9307-IRZ
- brandname: Cirrus Logic Inc.
- manufacturername: Cirrus Logic Inc.
Microprocessors - MPU IC Universal Platfrm ARM9 SOC Prcessor
- Brand: Cirrus Logic
- PartNumber: EP9307-IRZ
- Model: EP9307-IRZ
- PackageQuantity: 1
- Manufacturer: Cirrus Logic Inc
- Label: Cirrus Logic Inc
Attributes
| Key | Value |
|---|
| Additional Interfaces | AC'97, I?S, IrDA, SPI, . |
| Alternate Part No. | 777-EP9307-IRZ |
| Base Product Number | EP9307 |
| Brand | Cirrus Logic |
| Category | Integrated Circuits (IC. |
| Co-Processors/DSP | SDRAM, Math Engine; Mav. |
| Core | ARM920T |
| Core Processor | ARM920T, 1 Core, 32-Bit |
| Data Bus Width | 32 bit |
| Data RAM Size | 32 bit |
| Data ROM Size | 16 bit/32 bit |
| Description | IC MPU EP9 200MHZ 272TF. |
| Detailed Description | ARM920T Microprocessor . |
| Digi-Key Part Number | 598-1256-ND |
| Display & Interface Con. | Keypad, LCD, Touchscreen |
| Display & Interface. | 1/10/100Mbps (1) |
| Ethernet | -, 1/10/100Mbps (1) |
| Graphics Acceleration | Keypad, LCD, Touchscree. |
| I/O Voltage | 3.3 V |
| Interface Type | Ethernet, SPI, UART, USB |
| L1 Cache Instruction / . | 16 kB, 16 kB |
| Manufacturer | Cirrus Logic Inc., Cirr. |
| Manufacturer Part No. | EP9307-IRZ |
| Manufacturer Product Nu. | EP9307-IRZ |
| Maximum Clock Frequency | 200 MHz |
| Maximum Operating Tempe. | + 85 C |
| Mfr | Cirrus Logic Inc. |
| Minimum Operating Tempe. | - 40 C |
| Mounting Style | SMD/SMT |
| Mounting Type | Surface Mount |
| Number of Cores/Bus Wid. | 1 Core, 32-Bit, 200MHz |
| Number of I/Os | 32 I/O |
| Operating Supply Voltage | 1.8 V |
| Operating Temperature | -40?C ~ 85?C (TA), Hard. |
| Package | Not For New Designs, Tr. |
| Package / Case | 272-LFBGA, AC'97, I?S, . |
| Package/Case | TFBGA-272 |
| Part Status | ARM920T |
| Processor Series | EP93xx |
| Product Category | Microprocessors - MPU |
| Product Status | Obsolete |
| RAM Controllers | Yes, SDRAM |
| SATA | USB 2.0 (3), - |
| Security Features | Hardware ID, 272-LFBGA |
| Series | Tray, EP9307, EP9 |
| Speed | Math Engine; MaverickCr. |
| Tradename | EP9307 |
| USB | 1.8V, 3.3V, USB 2.0 (3) |
| Voltage - I/O | 1.8V, 3.3V, -40?C ~ 85?. |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Hotenda | H2381909 | 31.08 | 1 | In Stock | | Cirrus Logic, Inc. | | 31.08 @ 1 |
 | Digi-Key | 1245706 | 43.62 | 1 | 3 | | Cirrus Logic Inc. | | 43.62 @ 1 |
 | swatee.com | EP9307-IRZ | 53.89 | 1 | 130 | | Cirrus Logic | | 53.89 @ 1 |
| AmazonTP | B00MEKLLKW | 67.36 | 1 | In Stock | 10 | Cirrus Logic Inc | | 67.36 @ 1 |
