- mpnLEB225F-0512-SN
- brandname: Cosel U.S.A. Inc.
- manufacturername: Cosel U.S.A. Inc.
Switching Power Supplies AC/DC PS
- Brand: Cosel USA, Inc.
- PartNumber: LEB225F-0512-SN
- Model: LEB225F-0512-SN
- PackageQuantity: 1
Attributes
| Key | Value |
|---|
| Alternate Part No. | 436-LEB225F-0512-SN |
| Application | Remote control |
| Applications | ITE (Commercial) |
| Approval Agency | CE, cURus, TUV |
| Base Product Number | LEB225F |
| Brand | Cosel |
| Case Size | D 222 x W 95 x H 45 mm |
| Category | Power Supplies - Extern. |
| Commercial/Medical | Commercial |
| Configuration | Enclosed |
| Current - Output 1 | 5 A |
| Current - Output 2 | 20 A |
| Dimensions | 252 mm L x 108 mm W |
| Efficiency | 79%, 77 % (Typ.) @ 100 . |
| Frequency | 50/60 Hz |
| Height | 58 mm |
| Input Frequency | 50 Hz/60 Hz |
| Input Voltage | 100 VAC ; 110 VAC ; 115. |
| Input Voltage Range | 85-264 VAC |
| Isolation Voltage | 3 kV |
| Leakage Current | 0.75 mA (Max.) |
| Length | 252 mm |
| Line Regulation | 48 mV (Max.) |
| Load Regulation | 100 mV (Max.) |
| Manufacturer | Cosel |
| Manufacturer Part No. | LEB225F-0512-SN |
| Mfr | Cosel USA, Inc. |
| Minimum Load Required | No |
| Mounting Style | Chassis |
| Mounting Type | Panel Mount, Chassis Mo. |
| Number of Outputs | 2 Output, 2 |
| Open Frame/Enclosed | Enclosed |
| Operating Temperature | -10 to +70 ?C, -10?C ~ . |
| Operation | PFC |
| Output Current | 5A@5V, 10A@12V |
| Output Current-Channel 1 | 5 A |
| Output Current-Channel 2 | 10 A |
| Output Power | 145 W |
| Output Power Rating | 145 W |
| Output Voltage | 5 VDC, 12 VDC |
| Output Voltage-Channel 1 | 5 V |
| Output Voltage-Channel 2 | 12 V |
| Package | Box |
| Power - Convection | 225 W |
| Power Rating | 225 W |
| Primary Type | AC-DC |
| Product | Switching Supplies |
| Product Category | Switching Power Supplies |
| Product Header | LEB Series Rugged PCB T. |
| Product Status | Last Time Buy |
| Ripple Output | 120 mVp-p (Max.) |
| Series | LEB, LEB (225W), LEB Se. |
| Size / Dimension | 8.74" L x 3.74" W x 1.7. |
| Special Features | 2 Year Warranty |
| Standards | UL Recognized, CE Marked |
| Turn On Rise Time | 500 ms (Max.) |
| Type | Enclosed, Embedded, VAC. |
| Voltage - Input | 85 ~ 264 VAC |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | 12V |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 6 | - |
| Width | 108 mm |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Digi-Key | 7047108 | 200.16 | 1 | In Stock | | Cosel USA, Inc. | | 200.16 @ 1 |
| us.rs-online.com | 70161690 | 200.16 | 1 | In Stock | | Cosel U.S.A. Inc. | | 200.16 @ 1 |
| RS Delivers | 635-2357 | 206.82 | 1 | In Stock | | Cosel | | 206.82 @ 1 |
| Future Electronics | 2020833 | 250.992 | 1 | In Stock | | COSEL | | 250.992 @ 1 |
 | swatee.com | LEB225F-0512-SN | 389.81 | 1 | 2 | | Cosel | | 389.81 @ 1 |
