Crydom CL240A05C

B00LS9PXAY

Crydom CL240A05C Solid State Relay

Crydom CL240A05C Solid State Relayzoom

Attributes

Key Value
Auxiliary SwitchNo
Body Depth0.85 in
Body Depth - Relay2.32 in
Body Height2.25 in
Body Height - Relay0.89 in
Body Width1.75 in
Body Width - Relay1.75 in
Contact Form - RelaySPST-NO
Current Rating5 A
Family SeriesCrydom Relays, CL Series
Finger SafeYes
Gross Weight0 lbs
Heat SinkNot Included
Input or Control Voltage90 to 250V AC
Input PolarityAC
Input Power Consumption.0.7VA
Input Signal90-250 VAC
Input Voltage90 to 250V AC
Integral Heat SinkYes
ItemSolid State Relay
Item - RelaySolid State Relay
Item NumberCL240A05C
ManufacturerCrydom
Manufacturer Part NumberCL240A05C
Max. Output Amps w/Heat.5 A
Max. Output Amps Withou.2.9 A
Max. Output w/Heat Sink5A
MountingPanel
Mounting - RelaySurface
MOVNo
Net Weight0.2 lbs
Nominal Output Voltage12 VAC, 208 VAC, 277 VA.
Output or Controlled Vo.24 to 280V AC
Output Voltage24-280 VAC
Overall Depth0.92 in
Overall Height - Relay1.22 in
Product SeriesCL
Relay Turns On AtZero Crossing
SnubberNo
Status IndicatorYes
Switch TypeSCR
Switching TypeZero Cross
TerminationScrew Terminal
Transient Overvoltage600 V
Voltage Output24 to 280VAC

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
HotendaH386145040.751In StockCrydom40.75 @ 1
thumbzoomGalcoCL240A05C-CRDM50.951In StockCrydom0.250.95 @ 1
thumbzoomsustainablesupply.comC117124558.621In StockCrydom0.3558.62 @ 1
thumbzoomRadwellCL240A05C59.6810In StockCRYDOM59.68 @ 10
thumbzoomRaptor SuppliesAF7JWZ75.5775541In StockCRYDOM75.577554 @ 1
thumbzoomZoroG4476552799.81In StockCrydom0.35799.8 @ 1
