Crydom D53TP50C10

mpnD53TP50C-10
brandname: CRYDOM
manufacturername: CRYDOM

Crydom / CST - D53TP50C-10 - 3-Pole Surface Mount Solid State Relay; Max. Output Amps w/Heat Sink: 50

Crydom / CST - D53TP50C-10 - 3-Pole Surface Mount Solid State Relay; Max. Output Amps w/Heat Sink: 50

zoom

Brand: Crydom
PartNumber: D53TP50C10
Model: D53TP50C-10
PackageQuantity: 1
Manufacturer: CRYDOM
Label: CRYDOM

Attributes

Key	Value
Auxiliary Switch	No
Body Depth	2.89 in
Body Depth - Relay	2.89 in
Body Height	3.2 in
Body Height - Relay	0.79 in
Body Width	4.09 in
Body Width - Relay	4.09 in
Case Colour	Gray
Contact Form - Relay	(3) SPST-NO
Current Rating	50 A
Family Series	Crydom Relays, 53TP Ser.
Finger Safe	Yes
Gross Weight	0 lbs
Heat Sink	Not Included
Input or Control Voltage	4 to 32V DC
Input or Control Voltag.	4 to 32VDC
Input Polarity	AC/DC
Input Power Consumption.	0.3W, 0.3 W
Input Signal	4-32 VDC
Input Voltage	4 to 32V DC
Integral Heat Sink	No
Item	Solid State Relay
Item - Relay	Solid State Relay
Item Number	D53TP50C-10
Manufacturer	Crydom
Manufacturer Part Number	D53TP50C-10
Max. Output Amps w/Heat.	50 A, 50
Max. Output Amps Withou.	Not Recommended
Mounting	Surface, Panel
Mounting - Relay	Surface
MOV	No
Net Weight	0.82 lbs
Nominal Output Voltage	208 VAC, 277 VAC, 347 V.
Output or Controlled Vo.	48 to 530V AC
Output Voltage	48-530 VAC
Overall Depth	1.45 in
Overall Height - Relay	1.18 in
Product Series	53TP
Relay Turns On At	Instantaneous/Random
Snubber	No
Standards	CE, UL
Status Indicator	No
Switch Type	SCR
Switching Type	Random/Instantaneous
Termination	Screw Terminal
Transient Overvoltage	1,200 V
Voltage Output	48 to 530VAC

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Onlinecomponents.com	D53TP50C-10	152.25	1	50		Crydom		152.25 @ 50
	Digi-Key	D53TP50C-10-ND	191.05	10	50		Crydom Co.		191.05 @ 50
	sustainablesupply.com	C1171273	274.59	1	50		Crydom	1.0	274.59 @ 50
	grainger.ca	WWG21R954	277.62805306	1	50		CRYDOM	1.0	277.62805306 @ 50
	Galco	D53TP50C-10-CRDM	280.43	1	50		Crydom	0.82	280.43 @ 50
	Raptor Supplies	AF7JYE	400.9610475	1	50		CRYDOM		400.9610475 @ 50
	Radwell	D53TP50C-10	793.98	5	50		CRYDOM		793.98 @ 50
	Zoro	G4476823	2169.9	1	50		Crydom	1.0	2169.9 @ 50
